Fuse NH00 gG 690V top indicator 100A

    Fuse NH00 gG 690V top indicator 100A

    382065.0.0
    DF
    Available
    Class
    gG
    Rated current In (A)
    100
    Rated Voltage Un AC (V)
    690
    Rated break.capacity I1 AC (A)
    80000
    Voltage of total I2t test
    690
    Format
    NH knife contact
    Dimension
    NH00
    Pre-arcing I2t value (A2s)
    21000
    Total I2t value (A2s)
    75000
    Homologations
    IEC
    Power loss (W)
    9
    €8.25

    Catalog
    Fuse NH00 gG 690V top indicator 80A

      Fuse NH00 gG 690V top indicator 80A

      382060.0.0
      DF
      Available
      Class
      gG
      Rated current In (A)
      80
      Rated Voltage Un AC (V)
      690
      Rated break.capacity I1 AC (A)
      80000
      Voltage of total I2t test
      690
      Format
      NH knife contact
      Dimension
      NH00
      Pre-arcing I2t value (A2s)
      11700
      Total I2t value (A2s)
      41786
      Homologations
      IEC
      Power loss (W)
      7
      €8.25

      Catalog
      Fuse NH00 gG 690V top indicator 63A

        Fuse NH00 gG 690V top indicator 63A

        382055.0.0
        DF
        Available
        Class
        gG
        Rated current In (A)
        63
        Rated Voltage Un AC (V)
        690
        Rated break.capacity I1 AC (A)
        80000
        Voltage of total I2t test
        690
        Format
        NH knife contact
        Dimension
        NH00
        Pre-arcing I2t value (A2s)
        6600
        Total I2t value (A2s)
        23571
        Homologations
        IEC
        Power loss (W)
        6,1
        €8.25

        Catalog
        Fuse NH00 gG 690V top indicator 50A

          Fuse NH00 gG 690V top indicator 50A

          382050.0.0
          DF
          Available
          Class
          gG
          Rated current In (A)
          50
          Rated Voltage Un AC (V)
          690
          Rated break.capacity I1 AC (A)
          80000
          Voltage of total I2t test
          690
          Format
          NH knife contact
          Dimension
          NH00
          Pre-arcing I2t value (A2s)
          4800
          Total I2t value (A2s)
          14630
          Homologations
          IEC
          Power loss (W)
          4,7
          €8.25

          Catalog
          Fuse NH00 gG 690V top indicator 40A

            Fuse NH00 gG 690V top indicator 40A

            382045.0.0
            DF
            Available
            Class
            gG
            Rated current In (A)
            40
            Rated Voltage Un AC (V)
            690
            Rated break.capacity I1 AC (A)
            80000
            Voltage of total I2t test
            690
            Format
            NH knife contact
            Dimension
            NH00
            Pre-arcing I2t value (A2s)
            4650
            Total I2t value (A2s)
            11150
            Homologations
            IEC
            Power loss (W)
            4
            €8.11

            Catalog
            Fuse NH000/NH00C gG 690V top indicator 35A

              Fuse NH000/NH00C gG 690V top indicator 35A

              382040.0.0
              DF
              Available
              Class
              gG
              Rated current In (A)
              35
              Rated Voltage Un AC (V)
              690
              Rated break.capacity I1 AC (A)
              80000
              Voltage of total I2t test
              690
              Format
              NH knife contact
              Dimension
              NH00C NH000
              Pre-arcing I2t value (A2s)
              3517
              Total I2t value (A2s)
              7740
              Homologations
              IEC
              Power loss (W)
              3,5
              €8.11

              Catalog
              Fuse NH000/NH00C gG 690V top indicator 32A

                Fuse NH000/NH00C gG 690V top indicator 32A

                382035.0.0
                DF
                Available
                Class
                gG
                Rated current In (A)
                32
                Rated Voltage Un AC (V)
                690
                Rated break.capacity I1 AC (A)
                80000
                Voltage of total I2t test
                690
                Format
                NH knife contact
                Dimension
                NH00C NH000
                Pre-arcing I2t value (A2s)
                3064
                Total I2t value (A2s)
                6740
                Homologations
                IEC
                Power loss (W)
                3,3
                €8.11

                Catalog
                Fuse NH000/NH00C gG 690V top indicator 25A

                  Fuse NH000/NH00C gG 690V top indicator 25A

                  382030.0.0
                  DF
                  Available
                  Class
                  gG
                  Rated current In (A)
                  25
                  Rated Voltage Un AC (V)
                  690
                  Rated break.capacity I1 AC (A)
                  80000
                  Voltage of total I2t test
                  690
                  Format
                  NH knife contact
                  Dimension
                  NH00C NH000
                  Pre-arcing I2t value (A2s)
                  1120
                  Total I2t value (A2s)
                  4100
                  Homologations
                  IEC
                  Power loss (W)
                  2,8
                  €8.11

                  Catalog
                  Fuse NH000/NH00C gG 690V top indicator 20A

                    Fuse NH000/NH00C gG 690V top indicator 20A

                    382025.0.0
                    DF
                    Available
                    Class
                    gG
                    Rated current In (A)
                    20
                    Rated Voltage Un AC (V)
                    690
                    Rated break.capacity I1 AC (A)
                    80000
                    Voltage of total I2t test
                    690
                    Format
                    NH knife contact
                    Dimension
                    NH00C NH000
                    Pre-arcing I2t value (A2s)
                    584
                    Total I2t value (A2s)
                    2140
                    Homologations
                    IEC
                    Power loss (W)
                    2,3
                    €7.98

                    Catalog
                    Fuse NH000/NH00C gG 690V top indicator 16A

                      Fuse NH000/NH00C gG 690V top indicator 16A

                      382020.0.0
                      DF
                      Available
                      Class
                      gG
                      Rated current In (A)
                      16
                      Rated Voltage Un AC (V)
                      690
                      Rated break.capacity I1 AC (A)
                      80000
                      Voltage of total I2t test
                      690
                      Format
                      NH knife contact
                      Dimension
                      NH00C NH000
                      Pre-arcing I2t value (A2s)
                      255
                      Total I2t value (A2s)
                      935
                      Homologations
                      IEC
                      Power loss (W)
                      2
                      €7.92

                      Catalog
                      Fuse NH000/NH00C gG 690V top indicator 10A

                        Fuse NH000/NH00C gG 690V top indicator 10A

                        382015.0.0
                        DF
                        Available
                        Class
                        gG
                        Rated current In (A)
                        10
                        Rated Voltage Un AC (V)
                        690
                        Rated break.capacity I1 AC (A)
                        80000
                        Voltage of total I2t test
                        690
                        Format
                        NH knife contact
                        Dimension
                        NH00C NH000
                        Pre-arcing I2t value (A2s)
                        114
                        Total I2t value (A2s)
                        415
                        Homologations
                        IEC
                        Power loss (W)
                        1,1
                        €7.92

                        Catalog
                        Fuse NH000/NH00C gG 690V top indicator 6A

                          Fuse NH000/NH00C gG 690V top indicator 6A

                          382010.0.0
                          DF
                          Available
                          Class
                          gG
                          Rated current In (A)
                          6
                          Rated Voltage Un AC (V)
                          690
                          Rated break.capacity I1 AC (A)
                          80000
                          Voltage of total I2t test
                          690
                          Format
                          NH knife contact
                          Dimension
                          NH00C NH000
                          Pre-arcing I2t value (A2s)
                          103
                          Total I2t value (A2s)
                          300
                          Homologations
                          IEC
                          Power loss (W)
                          0,9
                          €8.24

                          Catalog
                          Fuse NH000/NH00C gG 690V top indicator 4A

                            Fuse NH000/NH00C gG 690V top indicator 4A

                            382005.0.0
                            DF
                            Available
                            Class
                            gG
                            Rated current In (A)
                            4
                            Rated Voltage Un AC (V)
                            690
                            Rated break.capacity I1 AC (A)
                            80000
                            Voltage of total I2t test
                            690
                            Format
                            NH knife contact
                            Dimension
                            NH00C NH000
                            Pre-arcing I2t value (A2s)
                            32
                            Total I2t value (A2s)
                            95
                            Homologations
                            IEC
                            Power loss (W)
                            0,65

                            Product available on request


                            Catalog
                            Fuse NH000/NH00C gG 690V top indicator 2A

                              Fuse NH000/NH00C gG 690V top indicator 2A

                              382000.0.0
                              DF
                              Available
                              Class
                              gG
                              Rated current In (A)
                              2
                              Rated Voltage Un AC (V)
                              690
                              Rated break.capacity I1 AC (A)
                              80000
                              Voltage of total I2t test
                              690
                              Format
                              NH knife contact
                              Dimension
                              NH00C NH000
                              Pre-arcing I2t value (A2s)
                              1,5
                              Total I2t value (A2s)
                              4,5
                              Homologations
                              IEC
                              Power loss (W)
                              0,83

                              Product available on request


                              Catalog
                              Fuse NH4 gG 500V top indicator 1250A

                                Fuse NH4 gG 500V top indicator 1250A

                                381535.0.0
                                DF
                                Available
                                Class
                                gG
                                Rated current In (A)
                                1250
                                Rated Voltage Un AC (V)
                                500
                                Rated break.capacity I1 AC (A)
                                120000
                                Voltage of total I2t test
                                500
                                Format
                                NH knife contact
                                Dimension
                                NH4
                                Pre-arcing I2t value (A2s)
                                7541100
                                Total I2t value (A2s)
                                18475700
                                Power loss (W)
                                108
                                €143.89

                                Catalog
                                Fuse NH4 gG 500V top indicator 1000A

                                  Fuse NH4 gG 500V top indicator 1000A

                                  381530.0.0
                                  DF
                                  Available
                                  Class
                                  gG
                                  Rated current In (A)
                                  1000
                                  Rated Voltage Un AC (V)
                                  500
                                  Rated break.capacity I1 AC (A)
                                  120000
                                  Voltage of total I2t test
                                  500
                                  Format
                                  NH knife contact
                                  Dimension
                                  NH4
                                  Pre-arcing I2t value (A2s)
                                  4310000
                                  Total I2t value (A2s)
                                  10560000
                                  Homologations
                                  IEC
                                  Power loss (W)
                                  80

                                  Product available on request


                                  Catalog
                                  Fuse NH4 gG 500V top indicator 900A

                                    Fuse NH4 gG 500V top indicator 900A

                                    381527.0.0
                                    DF
                                    Available
                                    Class
                                    gG
                                    Rated current In (A)
                                    900
                                    Rated Voltage Un AC (V)
                                    500
                                    Rated break.capacity I1 AC (A)
                                    120000
                                    Voltage of total I2t test
                                    500
                                    Format
                                    NH knife contact
                                    Dimension
                                    NH4
                                    Pre-arcing I2t value (A2s)
                                    3405500
                                    Total I2t value (A2s)
                                    8343400
                                    Homologations
                                    IEC
                                    Power loss (W)
                                    76

                                    Product available on request


                                    Catalog
                                    Fuse NH4 gG 500V top indicator 800A

                                      Fuse NH4 gG 500V top indicator 800A

                                      381525.0.0
                                      DF
                                      Available
                                      Class
                                      gG
                                      Rated current In (A)
                                      800
                                      Rated Voltage Un AC (V)
                                      500
                                      Rated break.capacity I1 AC (A)
                                      120000
                                      Voltage of total I2t test
                                      500
                                      Format
                                      NH knife contact
                                      Dimension
                                      NH4
                                      Pre-arcing I2t value (A2s)
                                      2248200
                                      Total I2t value (A2s)
                                      5507900
                                      Homologations
                                      IEC
                                      Power loss (W)
                                      68

                                      Product available on request


                                      Catalog
                                      Fuse NH4 gG 500V top indicator 630A

                                        Fuse NH4 gG 500V top indicator 630A

                                        381520.0.0
                                        DF
                                        Available
                                        Class
                                        gG
                                        Rated current In (A)
                                        630
                                        Rated Voltage Un AC (V)
                                        500
                                        Rated break.capacity I1 AC (A)
                                        120000
                                        Voltage of total I2t test
                                        500
                                        Format
                                        NH knife contact
                                        Dimension
                                        NH4
                                        Pre-arcing I2t value (A2s)
                                        1609600
                                        Total I2t value (A2s)
                                        3943600
                                        Homologations
                                        IEC
                                        Power loss (W)
                                        47

                                        Product available on request


                                        Catalog
                                        Fuse NH4 gG 500V top indicator 500A

                                          Fuse NH4 gG 500V top indicator 500A

                                          381515.0.0
                                          DF
                                          Available
                                          Class
                                          gG
                                          Rated current In (A)
                                          500
                                          Rated Voltage Un AC (V)
                                          500
                                          Rated break.capacity I1 AC (A)
                                          120000
                                          Voltage of total I2t test
                                          500
                                          Format
                                          NH knife contact
                                          Dimension
                                          NH4
                                          Pre-arcing I2t value (A2s)
                                          851400
                                          Total I2t value (A2s)
                                          2085900
                                          Homologations
                                          IEC
                                          Power loss (W)
                                          37

                                          Product available on request


                                          Catalog
                                          Fuse NH4 gG 500V top indicator 400A

                                            Fuse NH4 gG 500V top indicator 400A

                                            381510.0.0
                                            DF
                                            Available
                                            Class
                                            gG
                                            Rated current In (A)
                                            400
                                            Rated Voltage Un AC (V)
                                            500
                                            Rated break.capacity I1 AC (A)
                                            120000
                                            Voltage of total I2t test
                                            500
                                            Format
                                            NH knife contact
                                            Dimension
                                            NH4
                                            Pre-arcing I2t value (A2s)
                                            471400
                                            Total I2t value (A2s)
                                            1154800
                                            Homologations
                                            IEC
                                            Power loss (W)
                                            32,7

                                            Product available on request


                                            Catalog
                                            Fuse NH4 gG 500V top indicator 315A

                                              Fuse NH4 gG 500V top indicator 315A

                                              381505.0.0
                                              DF
                                              Available
                                              Class
                                              gG
                                              Rated current In (A)
                                              315
                                              Rated Voltage Un AC (V)
                                              500
                                              Rated break.capacity I1 AC (A)
                                              120000
                                              Voltage of total I2t test
                                              500
                                              Format
                                              NH knife contact
                                              Dimension
                                              NH4
                                              Pre-arcing I2t value (A2s)
                                              269400
                                              Total I2t value (A2s)
                                              660000
                                              Homologations
                                              IEC
                                              Power loss (W)
                                              26,1

                                              Product available on request


                                              Catalog
                                              Fuse NH3 gG 500V top indicator 800A

                                                Fuse NH3 gG 500V top indicator 800A

                                                381475.0.0
                                                DF
                                                Available
                                                Class
                                                gG
                                                Rated current In (A)
                                                800
                                                Rated Voltage Un AC (V)
                                                500
                                                Rated break.capacity I1 AC (A)
                                                120000
                                                Voltage of total I2t test
                                                500
                                                Format
                                                NH knife contact
                                                Dimension
                                                NH3
                                                Pre-arcing I2t value (A2s)
                                                2500000
                                                Total I2t value (A2s)
                                                7850000
                                                Power loss (W)
                                                66,5
                                                €63.51

                                                Catalog
                                                Fuse NH3 gG 500V top indicator 630A

                                                  Fuse NH3 gG 500V top indicator 630A

                                                  381470.0.0
                                                  DF
                                                  Available
                                                  Class
                                                  gG
                                                  Rated current In (A)
                                                  630
                                                  Rated Voltage Un AC (V)
                                                  500
                                                  Rated break.capacity I1 AC (A)
                                                  120000
                                                  Voltage of total I2t test
                                                  500
                                                  Format
                                                  NH knife contact
                                                  Dimension
                                                  NH3
                                                  Pre-arcing I2t value (A2s)
                                                  1600000
                                                  Total I2t value (A2s)
                                                  5020000
                                                  Homologations
                                                  IEC
                                                  Power loss (W)
                                                  45,5
                                                  €38.01

                                                  Catalog

                                                  Filter by

                                                  Manufacturer
                                                  more... less
                                                  Class
                                                  more... less
                                                  Rated Voltage Un AC (V)
                                                  32 1140
                                                  Rated Voltage Un DC (V)
                                                  400 1000
                                                  Rated current In (A)
                                                  0.16 1600
                                                  Format
                                                  more... less
                                                  Dimension
                                                  Homologations
                                                  more... less
                                                  Pre-arcing I2t value (A2s)
                                                  0.08 14000000
                                                  Total I2t value (A2s)
                                                  0.35 35000000
                                                  Low voltage fuses gG - aM
                                                  Product added to wishlist
                                                  Product added to compare.
