Low voltage fuses gG - aM

800GNH1 - Fuse NH1 800V gG 35A
  • New

800GNH1 - Fuse NH1 800V gG 35A

C17.296.77.0.0
TechnoTeam
Available
Class
gG
Rated current In (A)
35
Rated Voltage Un AC (V)
800
Rated break.capacity I1 AC (A)
80000
Voltage of total I2t test
800
Format
NH knife contact
Dimension
NH1
Pre-arcing I2t value (A2s)
2200
Total I2t value (A2s)
33000
Homologations
IEC
Power loss (W)
3,7

Product available on request


Datasheet
800GNH1 - Fuse NH1 800V gG 40A
  • New

800GNH1 - Fuse NH1 800V gG 40A

B77.629.41.0.0
TechnoTeam
Available
Class
gG
Rated current In (A)
40
Rated Voltage Un AC (V)
800
Rated break.capacity I1 AC (A)
80000
Voltage of total I2t test
800
Format
NH knife contact
Dimension
NH1
Pre-arcing I2t value (A2s)
2900
Total I2t value (A2s)
43500
Homologations
IEC
Power loss (W)
4,2

Product available on request


Datasheet
800GNH2 - Fuse NH2 800V gG 160A

    800GNH2 - Fuse NH2 800V gG 160A

    B71.328.71.0.0
    TechnoTeam
    Available
    Class
    gG
    Rated current In (A)
    160
    Rated Voltage Un AC (V)
    800
    Rated break.capacity I1 AC (A)
    80000
    Voltage of total I2t test
    800
    Format
    NH knife contact
    Dimension
    NH2
    Pre-arcing I2t value (A2s)
    42000
    Total I2t value (A2s)
    408000
    Homologations
    IEC
    Power loss (W)
    17,5

    Product available on request


    Datasheet
    10TD - Fuse 10x38 500VAC aM/aR 10A

      10TD - Fuse 10x38 500VAC aM/aR 10A

      922.606.35.0.0
      FAULTRAP
      Available
      Class
      aM-aR
      Rated current In (A)
      10
      Rated Voltage Un AC (V)
      500
      Rated break.capacity I1 AC (A)
      50000
      Voltage of total I2t test
      500
      Format
      Cylindrical
      Dimension
      10x38mm
      Pre-arcing I2t value (A2s)
      305
      Total I2t value (A2s)
      900
      Homologations
      IEC & UL

      Product available on request


      Catalog
      Fuse NH4L long gF 1000VDC 800A

        Fuse NH4L long gF 1000VDC 800A

        9008310.800.0
        SIBA
        Available
        Class
        gF
        Rated current In (A)
        800
        Voltage of total I2t test
        1000
        Format
        NH knife contact
        Dimension
        NH4L
        Pre-arcing I2t value (A2s)
        1030000
        Total I2t value (A2s)
        2900000
        Rated Voltage Un DC (V)
        1000
        Rated break.capacity I1 DC (A)
        40000
        Time costant L/R (ms)
        1

        Product available on request


        Catalog
        Datasheet
        Fuse NH4L long gF 1000VDC 700A

          Fuse NH4L long gF 1000VDC 700A

          9008310.700.0
          SIBA
          Available
          Class
          gF
          Rated current In (A)
          700
          Voltage of total I2t test
          1000
          Format
          NH knife contact
          Dimension
          NH4L
          Pre-arcing I2t value (A2s)
          695000
          Total I2t value (A2s)
          2000000
          Rated Voltage Un DC (V)
          1000
          Rated break.capacity I1 DC (A)
          40000
          Time costant L/R (ms)
          1

          Product available on request


          Catalog
          Datasheet
          Fuse NH4L long gF 1000VDC 630A

            Fuse NH4L long gF 1000VDC 630A

            9008310.630.0
            SIBA
            Available
            Class
            gF
            Rated current In (A)
            630
            Voltage of total I2t test
            1000
            Format
            NH knife contact
            Dimension
            NH4L
            Pre-arcing I2t value (A2s)
            480000
            Total I2t value (A2s)
            1400000
            Rated Voltage Un DC (V)
            1000
            Rated break.capacity I1 DC (A)
            40000
            Time costant L/R (ms)
            1

            Product available on request


            Catalog
            Datasheet
            Fuse NH4L long gF 1000VDC 550A

              Fuse NH4L long gF 1000VDC 550A

              9008310.550.0
              SIBA
              Available
              Class
              gF
              Rated current In (A)
              550
              Voltage of total I2t test
              1000
              Format
              NH knife contact
              Dimension
              NH4L
              Pre-arcing I2t value (A2s)
              330000
              Total I2t value (A2s)
              980000
              Rated Voltage Un DC (V)
              1000
              Rated break.capacity I1 DC (A)
              40000
              Time costant L/R (ms)
              1

              Product available on request


              Catalog
              Datasheet
              Fuse NH4L long gF 1000VDC 500A

                Fuse NH4L long gF 1000VDC 500A

                9008310.500.0
                SIBA
                Available
                Class
                gF
                Rated current In (A)
                500
                Voltage of total I2t test
                1000
                Format
                NH knife contact
                Dimension
                NH4L
                Pre-arcing I2t value (A2s)
                250000
                Total I2t value (A2s)
                750000
                Rated Voltage Un DC (V)
                1000
                Rated break.capacity I1 DC (A)
                40000
                Time costant L/R (ms)
                1

                Product available on request


                Catalog
                Datasheet
                Fuse NH4 long aF 1000VDC 1000A

                  Fuse NH4 long aF 1000VDC 1000A

                  9008310.1000.0
                  SIBA
                  Available
                  Class
                  aF
                  Rated current In (A)
                  1000
                  Voltage of total I2t test
                  1000
                  Format
                  NH knife contact
                  Dimension
                  NH4L
                  Pre-arcing I2t value (A2s)
                  1760000
                  Total I2t value (A2s)
                  7120000
                  Rated Voltage Un DC (V)
                  1000
                  Rated break.capacity I1 DC (A)
                  40000
                  Time costant L/R (ms)
                  1

                  Product available on request


                  Catalog
                  Datasheet
                  G103 - Fuse 500V 10x38 gG 8A
                  • New

                  G103 - Fuse 500V 10x38 gG 8A

                  898.934.30.0.0
                  FAULTRAP
                  Available
                  Class
                  gG
                  Rated current In (A)
                  8
                  Rated Voltage Un AC (V)
                  500
                  Rated break.capacity I1 AC (A)
                  100000
                  Voltage of total I2t test
                  500
                  Format
                  Cylindrical
                  Dimension
                  10x38mm
                  Pre-arcing I2t value (A2s)
                  6,3
                  Total I2t value (A2s)
                  50
                  Homologations
                  IEC
                  Power loss (W)
                  1,2

                  Product available on request


                  Catalog
                  10TD - Fuse 10x38 500VAC aM/aR 16A

                    10TD - Fuse 10x38 500VAC aM/aR 16A

                    863.903.84.0.0
                    FAULTRAP
                    Available
                    Class
                    aM-aR
                    Rated current In (A)
                    16
                    Rated Voltage Un AC (V)
                    500
                    Rated break.capacity I1 AC (A)
                    50000
                    Voltage of total I2t test
                    500
                    Format
                    Cylindrical
                    Dimension
                    10x38mm
                    Pre-arcing I2t value (A2s)
                    560
                    Total I2t value (A2s)
                    2060
                    Homologations
                    IEC & UL

                    Product available on request


                    Catalog
                    G103 - Fuse 500V 10x38 gG 40A
                    • New

                    G103 - Fuse 500V 10x38 gG 40A

                    860.346.75.0.0
                    FAULTRAP
                    Available
                    Class
                    gG
                    Rated current In (A)
                    40
                    Rated Voltage Un AC (V)
                    500
                    Rated break.capacity I1 AC (A)
                    100000
                    Voltage of total I2t test
                    500
                    Format
                    Cylindrical
                    Dimension
                    10x38mm
                    Pre-arcing I2t value (A2s)
                    100
                    Total I2t value (A2s)
                    638
                    Homologations
                    IEC
                    Power loss (W)
                    3

                    Product available on request


                    Catalog
                    10TD - Fuse 10x38 400VAC aM/aR 25A

                      10TD - Fuse 10x38 400VAC aM/aR 25A

                      828.304.38.0.0
                      FAULTRAP
                      Available
                      Class
                      aM-aR
                      Rated current In (A)
                      25
                      Rated Voltage Un AC (V)
                      400
                      Rated break.capacity I1 AC (A)
                      50000
                      Voltage of total I2t test
                      400
                      Format
                      Cylindrical
                      Dimension
                      10x38mm
                      Pre-arcing I2t value (A2s)
                      1320
                      Total I2t value (A2s)
                      3670
                      Homologations
                      IEC & UL

                      Product available on request


                      Catalog
                      10TD - Fuse 10x38 400VAC aM/aR 32A

                        10TD - Fuse 10x38 400VAC aM/aR 32A

                        801.116.71.0.0
                        FAULTRAP
                        Available
                        Class
                        aM-aR
                        Rated current In (A)
                        400
                        Rated Voltage Un AC (V)
                        32
                        Rated break.capacity I1 AC (A)
                        50000
                        Voltage of total I2t test
                        400
                        Format
                        Cylindrical
                        Dimension
                        10x38mm
                        Pre-arcing I2t value (A2s)
                        2540
                        Total I2t value (A2s)
                        6110
                        Homologations
                        IEC & UL

                        Product available on request


                        Catalog
                        G103 - Fuse 500V 10x38 gG 30A
                        • New

                        G103 - Fuse 500V 10x38 gG 30A

                        744.660.77.0.0
                        FAULTRAP
                        Available
                        Class
                        gG
                        Rated current In (A)
                        30
                        Rated Voltage Un AC (V)
                        500
                        Rated break.capacity I1 AC (A)
                        100000
                        Voltage of total I2t test
                        500
                        Format
                        Cylindrical
                        Dimension
                        10x38mm
                        Pre-arcing I2t value (A2s)
                        87
                        Total I2t value (A2s)
                        564
                        Homologations
                        IEC
                        Power loss (W)
                        2,6

                        Product available on request


                        Catalog
                        G108 - Fuse 1000V AC gG 10x85mm 2A

                          G108 - Fuse 1000V AC gG 10x85mm 2A

                          737.739.33.0.0
                          FAULTRAP
                          Available
                          Class
                          gG
                          Rated current In (A)
                          2
                          Rated Voltage Un AC (V)
                          1000
                          Rated break.capacity I1 AC (A)
                          30000
                          Voltage of total I2t test
                          1000
                          Format
                          Cylindrical
                          Dimension
                          10x85mm
                          Pre-arcing I2t value (A2s)
                          5
                          Total I2t value (A2s)
                          90
                          Homologations
                          IEC
                          Power loss (W)
                          0,85

                          Product available on request


                          Datasheet
                          G108 - Fuse 1000V AC gG 10x85mm 3A

                            G108 - Fuse 1000V AC gG 10x85mm 3A

                            677.846.19.0.0
                            FAULTRAP
                            Available
                            Class
                            gG
                            Rated current In (A)
                            3
                            Rated Voltage Un AC (V)
                            1000
                            Rated break.capacity I1 AC (A)
                            30000
                            Voltage of total I2t test
                            1000
                            Format
                            Cylindrical
                            Dimension
                            10x85mm
                            Pre-arcing I2t value (A2s)
                            20
                            Total I2t value (A2s)
                            360
                            Homologations
                            IEC
                            Power loss (W)
                            1,1

                            Product available on request


                            Datasheet
                            G103 - Fuse 500V 10x38 gG 15A
                            • New

                            G103 - Fuse 500V 10x38 gG 15A

                            670.538.30.0.0
                            FAULTRAP
                            Available
                            Class
                            gG
                            Rated current In (A)
                            15
                            Rated Voltage Un AC (V)
                            500
                            Rated break.capacity I1 AC (A)
                            100000
                            Voltage of total I2t test
                            500
                            Format
                            Cylindrical
                            Dimension
                            10x38mm
                            Pre-arcing I2t value (A2s)
                            14,5
                            Total I2t value (A2s)
                            141
                            Homologations
                            IEC
                            Power loss (W)
                            1,3

                            Product available on request


                            Catalog
                            G103 - Fuse 500V 10x38 gG 4A
                            • New

                            G103 - Fuse 500V 10x38 gG 4A

                            664.576.93.0.0
                            FAULTRAP
                            Available
                            Class
                            gG
                            Rated current In (A)
                            4
                            Rated Voltage Un AC (V)
                            500
                            Rated break.capacity I1 AC (A)
                            100000
                            Voltage of total I2t test
                            500
                            Format
                            Cylindrical
                            Dimension
                            10x38mm
                            Pre-arcing I2t value (A2s)
                            3,3
                            Total I2t value (A2s)
                            24
                            Homologations
                            IEC
                            Power loss (W)
                            0,8

                            Product available on request


                            Catalog
                            10TD - Fuse 10x38 400VAC aM/aR 20A

                              10TD - Fuse 10x38 400VAC aM/aR 20A

                              651.340.87.0.0
                              FAULTRAP
                              Available
                              Class
                              aM-aR
                              Rated current In (A)
                              20
                              Rated Voltage Un AC (V)
                              400
                              Rated break.capacity I1 AC (A)
                              50000
                              Voltage of total I2t test
                              400
                              Format
                              Cylindrical
                              Dimension
                              10x38mm
                              Pre-arcing I2t value (A2s)
                              960
                              Total I2t value (A2s)
                              2460
                              Homologations
                              IEC & UL

                              Product available on request


                              Catalog
                              Fuse 22x127mm F 1000VDC 63A

                                Fuse 22x127mm F 1000VDC 63A

                                6006212.63.0
                                SIBA
                                Available
                                Class
                                F
                                Rated current In (A)
                                63
                                Rated break.capacity I1 AC (A)
                                25000
                                Voltage of total I2t test
                                690
                                Format
                                Cylindrical
                                Dimension
                                22x127mm
                                Pre-arcing I2t value (A2s)
                                2300
                                Total I2t value (A2s)
                                28000
                                Power loss (W)
                                32,1
                                Rated Voltage Un DC (V)
                                1000
                                Rated break.capacity I1 DC (A)
                                25000
                                Resistance (ohm)
                                4,6
                                Time costant L/R (ms)
                                1
                                Resistance (Mohm)
                                4,6

                                Product available on request


                                Catalog
