Fuse NH1XL gPV UL 2579 1100V DC 150A

    Fuse NH1XL gPV UL 2579 1100V DC 150A

    SIBA
    2002829.150.0
    Product available on request

    Product Request:

    Fuse NH1XL gPV UL 2579 1100V DC 150A

    Fuse NH1XL gPV UL 2579 1100V DC 150A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 2 pcs

    This product has a minimum quantity of 2 and sold by 2

    Download

    Catalog Datasheet
    Class
    gPV
    Rated current In (A)
    150
    Voltage of total I2t test
    1100
    Weight (g)
    760
    Format
    NH knife contact
    Dimension
    NH1XL
    Pre-arcing I2t value (A2s)
    6700
    Total I2t value (A2s)
    22000
    Homologations
    IEC
    Power loss (W)
    34
    Rated Voltage Un DC (V)
    1100
    Rated break.capacity I1 DC (A)
    30000

    Accessories

    Fuse base metal/ceramic NH1XL 1500V gPV UL
      Available
      for NH knife fuses

      Fuse base metal/ceramic NH1XL 1500V gPV UL

      2102828.0.0
      Rated current In (A)
      250
      Homologations
      IEC & UL
      Fuses format
      NH knife contact
      Fuses dimension
      NH1XL
      Rated Voltage Un DC (V)
      1500
      Number of phase
      1
      Max power dissipation (W)
      32
      €104.17
      ZMMN - Fuse base NH1XL 1500VDC
        Available
        for NH knife fuses

        ZMMN - Fuse base NH1XL 1500VDC

        446.287.28.0.0
        Rated current In (A)
        250
        Rated Voltage Un AC (V)
        1500
        Homologations
        IEC
        Fuses format
        NH knife contact
        Fuses dimension
        NH1XL
        Rated Voltage Un DC (V)
        1500
        Number of phase
        1
        Distance (mm)
        232
        Max power dissipation (W)
        32
        €97.91
