Fuse 1500VDC NH3L gPV UL248-19 without indicator 400A

    Fuse 1500VDC NH3L gPV UL248-19 without indicator 400A

    SIBA
    2024328.400.0
    Product available on request

    Product Request:


    Fuse 1500VDC NH3L gPV UL248-19 without indicator 400A

    Fuse 1500VDC NH3L gPV UL248-19 without indicator 400A

    do not include special characters

    * Required fields



    Class
    gPV
    Rated current In (A)
    400
    Voltage of total I2t test
    1500
    Weight (g)
    2060
    Dimension
    NH3L
    Pre-arcing I2t value (A2s)
    106000
    Total I2t value (A2s)
    534000
    Homologations
    IEC
    Power loss (W)
    64
    Rated Voltage Un DC (V)
    1500
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    3
