Fuse 10x38 600VDC gPV/gR with pins 6A

    Fuse 10x38 600VDC gPV/gR with pins 6A

    SIBA
    5022626.6.0
    Product available on request

    Product Request:

    Fuse 10x38 600VDC gPV/gR with pins 6A

    Fuse 10x38 600VDC gPV/gR with pins 6A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog Datasheet
    Class
    gPV
    Rated current In (A)
    6
    Voltage of total I2t test
    600
    Weight (g)
    10
    Format
    Cylindrical
    Dimension
    10x38mm
    Pre-arcing I2t value (A2s)
    45
    Homologations
    IEC & UL
    Power loss (W)
    2,5
    Rated Voltage Un DC (V)
    600
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    5

    Alternatives

    Fuse 10x38 gR 1000V UL/900V IEC AC/DC with pins 6A
      Available
      Ultrarapid fuses aR - gR

      Fuse 10x38 gR 1000V UL/900V IEC AC/DC with pins 6A

      SIBA SIBA
      5021606.6.0
      Class
      gR
      Rated current In (A)
      6
      Rated Voltage Un AC (V)
      900
      Voltage of total I2t test
      1000
      Format
      Cylindrical
      Dimension
      10x38mm
      Pre-arcing I2t value (A2s)
      5
      Total I2t value (A2s)
      40
      Homologations
      UL
      Power loss (W)
      0,7
      Rated Voltage Un DC (V)
      1000
      Rated break.capacity I1 DC (A)
      30000
      Time costant L/R (ms)
      1

      Product available on request

      Fuse 10x38 gPV 1000VDC with pins 6A
        Available
        Fuses for photovoltaic applications

        Fuse 10x38 gPV 1000VDC with pins 6A

        SIBA SIBA
        5021626.6.0
        Class
        gPV
        Rated current In (A)
        6
        Voltage of total I2t test
        1000
        Format
        Cylindrical
        Dimension
        10x38mm
        Pre-arcing I2t value (A2s)
        45
        Homologations
        IEC & UL
        Power loss (W)
        2,5
        Rated Voltage Un DC (V)
        1000
        Rated break.capacity I1 DC (A)
        30000
        Time costant L/R (ms)
        2

        Product available on request

        Accessories

        ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P with ind
          Available
          for Cylindrical fuses

          ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P with ind

          421.781.29.0.0
          Rated current In (A)
          32
          Rated Voltage Un AC (V)
          690
          Homologations
          IEC
          Fuses format
          Cylindrical
          Fuses dimension
          10x38mm
          Rated Voltage Un DC (V)
          1000
          Number of phase
          1
          Max power dissipation (W)
          4,3
          €9.15
          ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P
            Available
            for Cylindrical fuses

            ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P

            793.159.36.0.0
            Rated current In (A)
            32
            Rated Voltage Un AC (V)
            690
            Homologations
            IEC
            Fuses format
            Cylindrical
            Fuses dimension
            10x38mm
            Rated Voltage Un DC (V)
            1000
            Number of phase
            2
            Max power dissipation (W)
            4,3
            €7.37
            ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P
              Available
              for Cylindrical fuses

              ZVJM - Fuse holder 10x38 690VAC-1000VDC 1P

              832.456.76.0.0
              Rated current In (A)
              32
              Rated Voltage Un AC (V)
              690
              Homologations
              IEC
              Fuses format
              Cylindrical
              Fuses dimension
              10x38mm
              Rated Voltage Un DC (V)
              1000
              Number of phase
              1
              Max power dissipation (W)
              4
              €3.04
              ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P with ind
                Available
                for Cylindrical fuses

                ZVJM - Fuse holder 10x38 690VAC-1000VDC 2P with ind

                543.991.81.0.0
                Rated current In (A)
                32
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC
                Fuses format
                Cylindrical
                Fuses dimension
                10x38mm
                Rated Voltage Un DC (V)
                1000
                Number of phase
                2
                Max power dissipation (W)
                4,3

                Product available on request
