Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 160A

    Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 160A

    SIBA
    2027834.160.0
    Product available on request

    Product Request:

    Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 160A

    Fuse SQB2 110mmgRL/gS 690VAC/500VDC lat switch adapt 90 160A

    do not include special characters

    * Required fields



    Download

    Catalog Datasheet
    Class
    gRL/gS
    Rated current In (A)
    160
    Rated Voltage Un AC (V)
    690
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    690
    Format
    Screw fixing
    Dimension
    SQB2-110mm
    Pre-arcing I2t value (A2s)
    7400
    Total I2t value (A2s)
    47000
    Homologations
    IEC
    Power loss (W)
    23
    Rated Voltage Un DC (V)
    500
    Rated break.capacity I1 DC (A)
    32000
    Time costant L/R (ms)
    15

    Accessories

    Fuse holder for SQB fuses size1-2-3 110mm 630A 1400V
      Available
      for Bolted fuses

      Fuse holder for SQB fuses size1-2-3 110mm 630A 1400V

      2132301.0.0
      Rated current In (A)
      630
      Rated Voltage Un AC (V)
      1400
      Homologations
      IEC & UL
      Fuses format
      Screw fixing
      Fuses dimension
      SQB1 SQB2 SQB3
      Number of phase
      1
      Distance (mm)
      110
      Max power dissipation (W)
      60
      €137.50
