Fuse 22x58 gRL/gS 690VAC/500VDC with striker 50A

    Fuse 22x58 gRL/gS 690VAC/500VDC with striker 50A

    SIBA
    5014234.50.0
    Product available on request

    Product Request:

    Fuse 22x58 gRL/gS 690VAC/500VDC with striker 50A

    Fuse 22x58 gRL/gS 690VAC/500VDC with striker 50A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog
    Class
    gRL/gS
    Rated current In (A)
    50
    Rated Voltage Un AC (V)
    700
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    690
    Weight (g)
    50
    Format
    Cylindrical
    Dimension
    22x58mm
    Pre-arcing I2t value (A2s)
    870
    Total I2t value (A2s)
    7000
    Homologations
    IEC & UL
    Power loss (W)
    0
    Rated Voltage Un DC (V)
    500
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    30

    Alternatives

    Fuse 22x58 gRL/gS 690VAC/500VDC 50A
      Available
      gRL/gS fuses

      Fuse 22x58 gRL/gS 690VAC/500VDC 50A

      SIBA SIBA
      5014034.50.0
      Class
      gRL/gS
      Rated current In (A)
      50
      Rated Voltage Un AC (V)
      700
      Rated break.capacity I1 AC (A)
      200000
      Voltage of total I2t test
      690
      Format
      Cylindrical
      Dimension
      22x58mm
      Pre-arcing I2t value (A2s)
      870
      Total I2t value (A2s)
      7000
      Homologations
      IEC & UL
      Rated Voltage Un DC (V)
      500
      Rated break.capacity I1 DC (A)
      30000
      Time costant L/R (ms)
      30

      Product available on request

      Accessories

      Fuse holder 22x58 690V 1p with switch(only fusion)(PMX)
        Available
        for Cylindrical fuses

        Fuse holder 22x58 690V 1p with switch(only fusion)(PMX)

        485326.0.0
        Rated current In (A)
        125
        Rated Voltage Un AC (V)
        690
        Homologations
        IEC & UL
        Fuses format
        Cylindrical
        Fuses dimension
        22x58mm
        Rated Voltage Un DC (V)
        750
        Number of phase
        1
        Max power dissipation (W)
        12
        €30.17
        Fuse holder 22x58 690V 2p with switch(only fusion)(PMX)
          Available
          for Cylindrical fuses

          Fuse holder 22x58 690V 2p with switch(only fusion)(PMX)

          485328.0.0
          Rated current In (A)
          125
          Rated Voltage Un AC (V)
          690
          Homologations
          IEC & UL
          Fuses format
          Cylindrical
          Fuses dimension
          22x58mm
          Rated Voltage Un DC (V)
          750
          Number of phase
          2
          Max power dissipation (W)
          12

          Product available on request

          Fuse holder 22x58 690V 2p switch(fusing+presence)(PMX)
            Available
            for Cylindrical fuses

            Fuse holder 22x58 690V 2p switch(fusing+presence)(PMX)

            485322.0.0
            Rated current In (A)
            125
            Rated Voltage Un AC (V)
            690
            Homologations
            IEC & UL
            Fuses format
            Cylindrical
            Fuses dimension
            22x58mm
            Rated Voltage Un DC (V)
            750
            Number of phase
            2
            Max power dissipation (W)
            12

            Product available on request

            Fuse holder22x58 690V IEC/750V UL 3p switch(fusing+presence)
              Available
              for Cylindrical fuses

              Fuse holder22x58 690V IEC/750V UL 3p switch(fusing+presence)

              5106005.3S.0
              Rated current In (A)
              100
              Rated Voltage Un AC (V)
              690
              Homologations
              IEC & UL
              Fuses format
              Cylindrical
              Fuses dimension
              22x58mm
              Rated Voltage Un DC (V)
              750
              Number of phase
              3
              Max power dissipation (W)
              12

              Product available on request

              Fuse holder22x58 3+N 690V switch(fusing+presence)(PMX)
                Available
                for Cylindrical fuses

                Fuse holder22x58 3+N 690V switch(fusing+presence)(PMX)

                485324.0.0
                Rated current In (A)
                125
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC & UL
                Fuses format
                Cylindrical
                Fuses dimension
                22x58mm
                Rated Voltage Un DC (V)
                750
                Number of phase
                3+N
                Max power dissipation (W)
                12

                Product available on request

                Fuse holder 22x58 3p 690V switch(fusing+presence)(PMX)
                  Available
                  for Cylindrical fuses

                  Fuse holder 22x58 3p 690V switch(fusing+presence)(PMX)

                  485323.0.0
                  Rated current In (A)
                  125
                  Rated Voltage Un AC (V)
                  690
                  Homologations
                  IEC & UL
                  Fuses format
                  Cylindrical
                  Fuses dimension
                  22x58mm
                  Rated Voltage Un DC (V)
                  750
                  Number of phase
                  3
                  Max power dissipation (W)
                  12
                  €44.75
                  Fuse holder22x58 690V IEC/750V UL 1p switch(fusing+presence)
                    Available
                    for Cylindrical fuses

                    Fuse holder22x58 690V IEC/750V UL 1p switch(fusing+presence)

                    5106005.1S.0
                    Rated current In (A)
                    100
                    Rated Voltage Un AC (V)
                    690
                    Homologations
                    IEC & UL
                    Fuses format
                    Cylindrical
                    Fuses dimension
                    22x58mm
                    Rated Voltage Un DC (V)
                    750
                    Number of phase
                    1
                    Max power dissipation (W)
                    12

                    Product available on request

                    Fuse holder 22x58 690V 3p with switch(only fusion)(PMX)
                      Available
                      for Cylindrical fuses

                      Fuse holder 22x58 690V 3p with switch(only fusion)(PMX)

                      485329.0.0
                      Rated current In (A)
                      125
                      Rated Voltage Un AC (V)
                      690
                      Homologations
                      IEC & UL
                      Fuses format
                      Cylindrical
                      Fuses dimension
                      22x58mm
                      Rated Voltage Un DC (V)
                      750
                      Number of phase
                      3
                      Max power dissipation (W)
                      12
                      €73.88
                      Fuse holder 22x58 690V 3+N with switch(only fusion)(PMX)
                        Available
                        for Cylindrical fuses

                        Fuse holder 22x58 690V 3+N with switch(only fusion)(PMX)

                        485330.0.0
                        Rated current In (A)
                        125
                        Rated Voltage Un AC (V)
                        690
                        Homologations
                        IEC & UL
                        Fuses format
                        Cylindrical
                        Fuses dimension
                        22x58mm
                        Rated Voltage Un DC (V)
                        750
                        Number of phase
                        3+N
                        Max power dissipation (W)
                        12

                        Product available on request

                        Fuse holder 22x58 690V 4p with switch(only fusion)(PMX)
                          Available
                          for Cylindrical fuses

                          Fuse holder 22x58 690V 4p with switch(only fusion)(PMX)

                          485331.0.0
                          Rated current In (A)
                          125
                          Rated Voltage Un AC (V)
                          690
                          Homologations
                          IEC & UL
                          Fuses format
                          Cylindrical
                          Fuses dimension
                          22x58mm
                          Rated Voltage Un DC (V)
                          750
                          Number of phase
                          4
                          Max power dissipation (W)
                          12

                          Product available on request

                          Fuse holder22x58 4p 690V switch(fusing+presence)(PMX)
                            Available
                            for Cylindrical fuses

                            Fuse holder22x58 4p 690V switch(fusing+presence)(PMX)

                            485325.0.0
                            Rated current In (A)
                            125
                            Rated Voltage Un AC (V)
                            690
                            Homologations
                            IEC & UL
                            Fuses format
                            Cylindrical
                            Fuses dimension
                            22x58mm
                            Rated Voltage Un DC (V)
                            750
                            Number of phase
                            4
                            Max power dissipation (W)
                            12

                            Product available on request

                            Fuse holder 22x58 690V 1+N with switch(only fusion)(PMX)
                              Available
                              for Cylindrical fuses

                              Fuse holder 22x58 690V 1+N with switch(only fusion)(PMX)

                              485327.0.0
                              Rated current In (A)
                              125
                              Rated Voltage Un AC (V)
                              690
                              Homologations
                              IEC & UL
                              Fuses format
                              Cylindrical
                              Fuses dimension
                              22x58mm
                              Rated Voltage Un DC (V)
                              750
                              Number of phase
                              1+N
                              Max power dissipation (W)
                              12

                              Product available on request

                              Fuse holder 22x58 690V 1+N with switch(fusing+presence)(PMX)
                                Available
                                for Cylindrical fuses

                                Fuse holder 22x58 690V 1+N with switch(fusing+presence)(PMX)

                                485321.0.0
                                Rated current In (A)
                                125
                                Rated Voltage Un AC (V)
                                690
                                Homologations
                                IEC & UL
                                Fuses format
                                Cylindrical
                                Fuses dimension
                                22x58mm
                                Rated Voltage Un DC (V)
                                750
                                Number of phase
                                1+N
                                Max power dissipation (W)
                                12

                                Product available on request

                                Fuse holder22x58 690V IEC/750V UL 2p switch(fusing+presence)
                                  Available
                                  for Cylindrical fuses

                                  Fuse holder22x58 690V IEC/750V UL 2p switch(fusing+presence)

                                  5106005.2S.0
                                  Rated current In (A)
                                  100
                                  Rated Voltage Un AC (V)
                                  690
                                  Homologations
                                  IEC & UL
                                  Fuses format
                                  Cylindrical
                                  Fuses dimension
                                  22x58mm
                                  Rated Voltage Un DC (V)
                                  750
                                  Number of phase
                                  2
                                  Max power dissipation (W)
                                  12

                                  Product available on request
