Fuse 22x58 gRL/gS 690VAC/500VDC 100A

    Fuse 22x58 gRL/gS 690VAC/500VDC 100A

    SIBA
    5014034.100.0
    Product available on request

    Product Request:

    Fuse 22x58 gRL/gS 690VAC/500VDC 100A

    Fuse 22x58 gRL/gS 690VAC/500VDC 100A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog
    Class
    gRL/gS
    Rated current In (A)
    100
    Rated Voltage Un AC (V)
    700
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    690
    Weight (g)
    60
    Format
    Cylindrical
    Dimension
    22x58mm
    Pre-arcing I2t value (A2s)
    4600
    Total I2t value (A2s)
    37000
    Homologations
    IEC & UL
    Power loss (W)
    0
    Rated Voltage Un DC (V)
    500
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    30

    Alternatives

    Fuse 22x58 gRL/gS 690VAC/500VDC with striker 100A
      Available
      gRL/gS fuses

      Fuse 22x58 gRL/gS 690VAC/500VDC with striker 100A

      SIBA SIBA
      5014234.100.0
      Class
      gRL/gS
      Rated current In (A)
      100
      Rated Voltage Un AC (V)
      700
      Rated break.capacity I1 AC (A)
      200000
      Voltage of total I2t test
      690
      Format
      Cylindrical
      Dimension
      22x58mm
      Pre-arcing I2t value (A2s)
      4600
      Total I2t value (A2s)
      37000
      Homologations
      IEC & UL
      Rated Voltage Un DC (V)
      500
      Rated break.capacity I1 DC (A)
      30000
      Time costant L/R (ms)
      30

      Product available on request

      Accessories

      Fuse holder 22x58 690V IEC / 750V UL 1pole with light
        Available
        for Cylindrical fuses

        Fuse holder 22x58 690V IEC / 750V UL 1pole with light

        5106005.1L.0
        Rated current In (A)
        100
        Rated Voltage Un AC (V)
        690
        Homologations
        IEC & UL
        Fuses format
        Cylindrical
        Fuses dimension
        22x58mm
        Rated Voltage Un DC (V)
        750
        Number of phase
        1
        Max power dissipation (W)
        12
        €23.04
        Fuse holder 22x58 690V IEC / 750V UL 2poles with light
          Available
          for Cylindrical fuses

          Fuse holder 22x58 690V IEC / 750V UL 2poles with light

          5106005.2L.0
          Rated current In (A)
          100
          Rated Voltage Un AC (V)
          690
          Homologations
          IEC & UL
          Fuses format
          Cylindrical
          Fuses dimension
          22x58mm
          Rated Voltage Un DC (V)
          750
          Number of phase
          2
          Max power dissipation (W)
          12

          Product available on request

          Fuse holder 22x58 690V IEC / 750V UL 1pole
            Available
            for Cylindrical fuses

            Fuse holder 22x58 690V IEC / 750V UL 1pole

            5106005.1.0
            Rated current In (A)
            100
            Rated Voltage Un AC (V)
            690
            Homologations
            IEC & UL
            Fuses format
            Cylindrical
            Fuses dimension
            22x58mm
            Rated Voltage Un DC (V)
            750
            Number of phase
            1
            Max power dissipation (W)
            12
            €18.40
            Clip diameter 14mm with holes
              Available
              for Cylindrical fuses

              Clip diameter 14mm with holes

              6100101.2.0
              Homologations
              IEC & UL
              Fuses format
              Cylindrical
              Inside diameter (mm)
              14

              Product available on request

              Fuse holder 22x58 690V IEC / 750V UL 2poles
                Available
                for Cylindrical fuses

                Fuse holder 22x58 690V IEC / 750V UL 2poles

                5106005.2.0
                Rated current In (A)
                100
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC & UL
                Fuses format
                Cylindrical
                Fuses dimension
                22x58mm
                Rated Voltage Un DC (V)
                750
                Number of phase
                2
                Max power dissipation (W)
                12
                Rated insultaion voltage AC (V)
                750
                €38.32
                Fuse holder 22x58 690V IEC / 750V UL 3poles
                  Available
                  for Cylindrical fuses

                  Fuse holder 22x58 690V IEC / 750V UL 3poles

                  5106005.3.0
                  Rated current In (A)
                  100
                  Rated Voltage Un AC (V)
                  690
                  Homologations
                  IEC & UL
                  Fuses format
                  Cylindrical
                  Fuses dimension
                  22x58mm
                  Rated Voltage Un DC (V)
                  750
                  Number of phase
                  3
                  Max power dissipation (W)
                  12
                  €57.11
                  Fuse holder 22x58 690V IEC / 750V UL 3poles with light
                    Available
                    for Cylindrical fuses

                    Fuse holder 22x58 690V IEC / 750V UL 3poles with light

                    5106005.3L.0
                    Rated current In (A)
                    100
                    Rated Voltage Un AC (V)
                    690
                    Homologations
                    IEC & UL
                    Fuses format
                    Cylindrical
                    Fuses dimension
                    22x58mm
                    Rated Voltage Un DC (V)
                    750
                    Number of phase
                    3
                    Max power dissipation (W)
                    12
                    €86.41
