Fuse 10x38 gG 500V 6A

Manufacturer: DF

Reference 420006.0.0

€0.86

VAT excl.

Product Details

Class: gG
Rated current In (A): 6
Rated Voltage Un AC (V): 500
Rated break.capacity I1 AC (A): 120000
Voltage of total I2t test: 500
Weight (g): 8
Format: Cylindrical
Dimension: 10x38mm
Pre-arcing I2t value (A2s): 70
Total I2t value (A2s): 166
Homologations: IEC
Power loss (W): 0,85
