Fuse NH3C gG 500V with top indicator 400A

    Fuse NH3C gG 500V with top indicator 400A

    DF
    381455.0.0
    €31.96
    VAT excl.

    Product Request:

    Fuse NH3C gG 500V with top indicator 400A

    Fuse NH3C gG 500V with top indicator 400A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 3 pcs

    This product has a minimum quantity of 3 and sold by 3

    Download

    Catalog
    Class
    gG
    Rated current In (A)
    400
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    500
    Weight (g)
    620
    Format
    NH knife contact
    Dimension
    NH3C
    Pre-arcing I2t value (A2s)
    444000
    Total I2t value (A2s)
    1670000
    Homologations
    IEC
    Power loss (W)
    32,6

    Accessories

    Fuse base 690V/800V NH3 1pole DIN rail or screw fixing
      Available
      for NH knife fuses

      Fuse base 690V/800V NH3 1pole DIN rail or screw fixing

      352630.0.0
      Rated current In (A)
      630
      Rated Voltage Un AC (V)
      800
      Homologations
      IEC
      Fuses format
      NH knife contact
      Fuses dimension
      NH3
      Rated Voltage Un DC (V)
      750
      Number of phase
      1
      Max power dissipation (W)
      60
      €45.96
      Fuse holder NH3 690V
        Available
        for NH knife fuses

        Fuse holder NH3 690V

        2100501.0.0
        Rated current In (A)
        630
        Rated Voltage Un AC (V)
        690
        Homologations
        IEC
        Fuses format
        NH knife contact
        Fuses dimension
        NH3
        Number of phase
        1
        Max power dissipation (W)
        60
        €43.18
        ZLYF - Fuse base NH3 1000VDC 1 pole
          Available
          for NH knife fuses

          ZLYF - Fuse base NH3 1000VDC 1 pole

          309.027.11.0.0
          Rated current In (A)
          630
          Rated Voltage Un AC (V)
          1000
          Homologations
          IEC
          Fuses format
          NH knife contact
          Fuses dimension
          NH3
          Rated Voltage Un DC (V)
          1500
          Number of phase
          1
          Distance (mm)
          210
          Max power dissipation (W)
          60

          Product available on request

          Switch disconnector NH3 3P top screw terminal - Busbar 60mm
            Available
            Horizontal switch disconnectors for NH fuses

            Switch disconnector NH3 3P top screw terminal - Busbar 60mm

            63-028802-004.0.0
            Rated current In (A)
            630
            Rated Voltage Un AC (V)
            690
            Homologations
            IEC
            Fuses format
            NH knife contact
            Fuses dimension
            NH3
            Rated Voltage Un DC (V)
            440
            Number of phase
            3

            Product available on request

            Switch disc. NH3 3P bottom screw terminal -Busbar 60mm
              Available
              Horizontal switch disconnectors for NH fuses

              Switch disc. NH3 3P bottom screw terminal -Busbar 60mm

              63-028802-003.0.0
              Rated current In (A)
              630
              Rated Voltage Un AC (V)
              690
              Homologations
              IEC
              Fuses format
              NH knife contact
              Fuses dimension
              NH3
              Rated Voltage Un DC (V)
              440
              Number of phase
              3
              €614.78
              Switch disconnector NH3 3P bridge clamps
                Available
                Horizontal switch disconnectors for NH fuses

                Switch disconnector NH3 3P bridge clamps

                63-811761-011.0.0
                Rated current In (A)
                630
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC
                Fuses format
                NH knife contact
                Fuses dimension
                NH3
                Rated Voltage Un DC (V)
                440
                Number of phase
                3

                Product available on request

                Switch disconnector NH3 3P screw terminal
                  Available
                  Horizontal switch disconnectors for NH fuses

                  Switch disconnector NH3 3P screw terminal

                  63-811761-021.0.0
                  Rated current In (A)
                  630
                  Rated Voltage Un AC (V)
                  690
                  Homologations
                  IEC
                  Fuses format
                  NH knife contact
                  Fuses dimension
                  NH3
                  Rated Voltage Un DC (V)
                  440
                  Number of phase
                  3
                  €313.54
                  Switch disc. NH3 3P bottom bridge clamps - Busbar 60mm
                    Available
                    Horizontal switch disconnectors for NH fuses

                    Switch disc. NH3 3P bottom bridge clamps - Busbar 60mm

                    63-028802-001.0.0
                    Rated current In (A)
                    630
                    Rated Voltage Un AC (V)
                    690
                    Homologations
                    IEC
                    Fuses format
                    NH knife contact
                    Fuses dimension
                    NH3
                    Rated Voltage Un DC (V)
                    440
                    Number of phase
                    3

                    Product available on request

                    Switch disconnector NH3 3P top bridge clamps - Busbar 60mm
                      Available
                      Horizontal switch disconnectors for NH fuses

                      Switch disconnector NH3 3P top bridge clamps - Busbar 60mm

                      63-028802-002.0.0
                      Rated current In (A)
                      630
                      Rated Voltage Un AC (V)
                      690
                      Homologations
                      IEC
                      Fuses format
                      NH knife contact
                      Fuses dimension
                      NH3
                      Rated Voltage Un DC (V)
                      440
                      Number of phase
                      3

                      Product available on request

                      Switch disconnector NH3 3P doubleV-terminal clamps
                        Available
                        Horizontal switch disconnectors for NH fuses

                        Switch disconnector NH3 3P doubleV-terminal clamps

                        63-811761-031.0.0
                        Rated current In (A)
                        630
                        Rated Voltage Un AC (V)
                        690
                        Homologations
                        IEC
                        Fuses format
                        NH knife contact
                        Fuses dimension
                        NH3
                        Rated Voltage Un DC (V)
                        440
                        Number of phase
                        3

                        Product available on request

                        Swich disconn. NH3 3P BS 690V conn. screw
                          Available
                          Horizontal switch disconnectors for NH fuses

                          Swich disconn. NH3 3P BS 690V conn. screw

                          335195.0.0
                          Rated current In (A)
                          630
                          Rated Voltage Un AC (V)
                          690
                          Homologations
                          IEC
                          Fuses format
                          NH knife contact
                          Fuses dimension
                          NH3
                          Number of phase
                          3
                          Max power dissipation (W)
                          48

                          Product available on request

                          Vert. switch NH3 690V 1poles switching M12
                            Available
                            Vertical switch disconnectors 800V for NH fuses

                            Vert. switch NH3 690V 1poles switching M12

                            63-001340-004.0.0
                            Rated current In (A)
                            630
                            Rated Voltage Un AC (V)
                            690
                            Homologations
                            IEC
                            Fuses format
                            NH knife contact
                            Fuses dimension
                            NH3

                            Product available on request

                            Vert. switch NH3 690V 1poles switching 2V
                              Available
                              Vertical switch disconnectors 800V for NH fuses

                              Vert. switch NH3 690V 1poles switching 2V

                              63-001340-006.0.0
                              Rated current In (A)
                              630
                              Rated Voltage Un AC (V)
                              690
                              Homologations
                              IEC
                              Fuses format
                              NH knife contact
                              Fuses dimension
                              NH3

                              Product available on request

                              Vert. switch NH3 690V 3poles switching V
                                Available
                                Vertical switch disconnectors 800V for NH fuses

                                Vert. switch NH3 690V 3poles switching V

                                63-001341-002.0.0
                                Rated current In (A)
                                630
                                Rated Voltage Un AC (V)
                                690
                                Homologations
                                IEC
                                Fuses format
                                NH knife contact
                                Fuses dimension
                                NH3

                                Product available on request

                                Vert. switch NH3 690V 3poles switching M12
                                  Available
                                  Vertical switch disconnectors 800V for NH fuses

                                  Vert. switch NH3 690V 3poles switching M12

                                  63-001341-004.0.0
                                  Rated current In (A)
                                  630
                                  Rated Voltage Un AC (V)
                                  690
                                  Homologations
                                  IEC
                                  Fuses format
                                  NH knife contact
                                  Fuses dimension
                                  NH3

                                  Product available on request

                                  Vert. switch NH3 690V 3poles switching 2V
                                    Available
                                    Vertical switch disconnectors 800V for NH fuses

                                    Vert. switch NH3 690V 3poles switching 2V

                                    63-001341-006.0.0
                                    Rated current In (A)
                                    630
                                    Rated Voltage Un AC (V)
                                    690
                                    Homologations
                                    IEC
                                    Fuses format
                                    NH knife contact
                                    Fuses dimension
                                    NH3

                                    Product available on request

                                    Vert. switch NH3 690V 3poles switching w. fuse mon.
                                      Available
                                      Vertical switch disconnectors 800V for NH fuses

                                      Vert. switch NH3 690V 3poles switching w. fuse mon.

                                      63-200401-566.0.0
                                      Rated current In (A)
                                      630
                                      Rated Voltage Un AC (V)
                                      690
                                      Homologations
                                      IEC
                                      Fuses format
                                      NH knife contact
                                      Fuses dimension
                                      NH3

                                      Product available on request
