Fuse 800V NH1 gG 160A

    Fuse 800V NH1 gG 160A

    DF
    385255.0.0
    Product available on request

    Product Request:

    Fuse 800V NH1 gG 160A

    Fuse 800V NH1 gG 160A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 3 pcs

    This product has a minimum quantity of 3 and sold by 3

    Download

    Catalog Datasheet
    Class
    gG
    Rated current In (A)
    160
    Rated Voltage Un AC (V)
    800
    Rated break.capacity I1 AC (A)
    80000
    Voltage of total I2t test
    800
    Weight (g)
    380
    Format
    NH knife contact
    Dimension
    NH1
    Pre-arcing I2t value (A2s)
    95300
    Total I2t value (A2s)
    195000
    Homologations
    IEC
    Power loss (W)
    18
    Supplier
    7

    Accessories

    Base NH1 800V AC/ 750V DC 3 pole DIN rail or screw Base NH1 800V AC/ 750V DC 3 pole DIN rail or screw 2
      Available
      for NH knife fuses

      Base NH1 800V AC/ 750V DC 3 pole DIN rail or screw

      353300.0.0
      Rated current In (A)
      250
      Rated Voltage Un AC (V)
      800
      Homologations
      IEC
      Fuses format
      NH knife contact
      Fuses dimension
      NH1
      Rated Voltage Un DC (V)
      750
      Number of phase
      3
      Max power dissipation (W)
      36

      Product available on request

      Base NH1 800V AC / 750V DC 1 pole DIN rail or screw fixing
        Available
        for NH knife fuses

        Base NH1 800V AC / 750V DC 1 pole DIN rail or screw fixing

        352300.0.0
        Rated current In (A)
        250
        Rated Voltage Un AC (V)
        800
        Homologations
        IEC
        Fuses format
        NH knife contact
        Fuses dimension
        NH1
        Rated Voltage Un DC (V)
        750
        Number of phase
        1
        Max power dissipation (W)
        36

        Product available on request

        Vertical switch disconn. NH1 800V Steel V connection 315A
          Available
          Vertical switch disconnectors 800V for NH fuses

          Vertical switch disconn. NH1 800V Steel V connection 315A

          438.71.10.55.00E8-C.0.0
          Rated current In (A)
          315
          Rated Voltage Un AC (V)
          800
          Homologations
          IEC
          Fuses format
          NH knife contact
          Fuses dimension
          NH1
          Number of phase
          3

          Product available on request

          Vertical switch disconn. NH1 800V Steel V connection 315A
            Available
            Vertical switch disconnectors 800V for NH fuses

            Vertical switch disconn. NH1 800V Steel V connection 315A

            438.71.10.55.00E8-S.0.0
            Rated current In (A)
            315
            Rated Voltage Un AC (V)
            800
            Homologations
            IEC
            Fuses format
            NH knife contact
            Fuses dimension
            NH1
            Number of phase
            3

            Product available on request

            Vert. switch NH1/2 800V 3poles switching V
              Available
              Vertical switch disconnectors 800V for NH fuses

              Vert. switch NH1/2 800V 3poles switching V

              63-073822-001.0.0
              Rated current In (A)
              200
              Rated Voltage Un AC (V)
              800
              Homologations
              IEC
              Fuses format
              NH knife contact
              Fuses dimension
              NH1 NH2
              Number of phase
              3
              Max power dissipation (W)
              21

              Product available on request

              Vert. switch NH1/2 800V 3poles switching M12
                Available
                Vertical switch disconnectors 800V for NH fuses

                Vert. switch NH1/2 800V 3poles switching M12

                63-073822-003.0.0
                Rated current In (A)
                200
                Rated Voltage Un AC (V)
                800
                Homologations
                IEC
                Fuses format
                NH knife contact
                Fuses dimension
                NH1 NH2
                Number of phase
                3
                Max power dissipation (W)
                21

                Product available on request

                Vert. switch NH1/2 800V 3poles switching 2V
                  Available
                  Vertical switch disconnectors 800V for NH fuses

                  Vert. switch NH1/2 800V 3poles switching 2V

                  63-073822-005.0.0
                  Rated current In (A)
                  200
                  Rated Voltage Un AC (V)
                  800
                  Homologations
                  IEC
                  Fuses format
                  NH knife contact
                  Fuses dimension
                  NH1 NH2
                  Number of phase
                  3
                  Max power dissipation (W)
                  21

                  Product available on request
