Fuse NH000 gG 500V double indicator 2A

    Fuse NH000 gG 500V double indicator 2A

    SIBA
    2000013.2.0
    Product available on request

    Product Request:

    Fuse NH000 gG 500V double indicator 2A

    Fuse NH000 gG 500V double indicator 2A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog Datasheet
    Class
    gG
    Rated current In (A)
    2
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    440
    Weight (g)
    128
    Format
    NH knife contact
    Dimension
    NH00C NH000
    Pre-arcing I2t value (A2s)
    2
    Total I2t value (A2s)
    8
    Homologations
    IEC
    Power loss (W)
    0,9
    Rated break.capacity I1 DC (A)
    25000
    Time costant L/R (ms)
    15
