Fuse NH000 gG 500V double indicator 63A

    Fuse NH000 gG 500V double indicator 63A

    SIBA
    2000013.63.0
    €5.11
    VAT excl.

    Product Request:

    Fuse NH000 gG 500V double indicator 63A

    Fuse NH000 gG 500V double indicator 63A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 10 pcs

    This product has a minimum quantity of 10 and sold by 10

    Download

    Catalog Datasheet
    Class
    gG
    Rated current In (A)
    63
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    440
    Weight (g)
    116
    Format
    NH knife contact
    Dimension
    NH00C NH000
    Pre-arcing I2t value (A2s)
    10300
    Total I2t value (A2s)
    26400
    Homologations
    IEC
    Power loss (W)
    4,5
    Rated break.capacity I1 DC (A)
    25000
    Time costant L/R (ms)
    15
