Fuse NH000/NH00C gG 500V top indicator 63A

    Fuse NH000/NH00C gG 500V top indicator 63A

    DF
    381055.0.0
    €5.48
    VAT excl.

    Product Request:

    Fuse NH000/NH00C gG 500V top indicator 63A

    Fuse NH000/NH00C gG 500V top indicator 63A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 3 pcs

    This product has a minimum quantity of 3 and sold by 3

    Download

    Catalog
    Class
    gG
    Rated current In (A)
    63
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    500
    Weight (g)
    120
    Format
    NH knife contact
    Dimension
    NH00C NH000
    Pre-arcing I2t value (A2s)
    5700
    Total I2t value (A2s)
    22000
    Homologations
    IEC
    Power loss (W)
    6,1

    Accessories

    Fuse holder metal/ceramic NH00 160A 1pole
      Available
      for NH knife fuses

      Fuse holder metal/ceramic NH00 160A 1pole

      2100101.0.0
      Rated current In (A)
      160
      Rated Voltage Un AC (V)
      690
      Homologations
      IEC
      Fuses format
      NH knife contact
      Fuses dimension
      NH00
      Number of phase
      1
      Max power dissipation (W)
      12

      Product available on request
