Fuse DIN000 80mm aR 700VDC with ind, w/o switch adapter 180A

    Fuse DIN000 80mm aR 700VDC with ind, w/o switch adapter 180A

    SIBA
    2029220.180.0
    Product available on request

    Product Request:

    Fuse DIN000 80mm aR 700VDC with ind, w/o switch adapter 180A

    Fuse DIN000 80mm aR 700VDC with ind, w/o switch adapter 180A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 6 pcs

    This product has a minimum quantity of 6 and sold by 6

    Download

    Catalog Datasheet
    Class
    aR
    Rated current In (A)
    180
    Voltage of total I2t test
    700
    Weight (g)
    120
    Format
    Screw fixing
    Dimension
    000-80mm
    Homologations
    UL
    Rated Voltage Un DC (V)
    700
    Rated break.capacity I1 DC (A)
    30000
    Time costant L/R (ms)
    1

    Accessories

    Fuse holder for DIN000-00 80mm 1000V 400A
      Available
      for Bolted fuses

      Fuse holder for DIN000-00 80mm 1000V 400A

      2118901.0.0
      Rated current In (A)
      400
      Rated Voltage Un AC (V)
      1000
      Homologations
      IEC & UL
      Fuses format
      Screw fixing
      Fuses dimension
      80mm
      Number of phase
      1
      Distance (mm)
      80
      Max power dissipation (W)
      34
      €24.35
      Fuse holder for DIN000-00 80mm +cover 1000V 400A
        Available
        for Bolted fuses

        Fuse holder for DIN000-00 80mm +cover 1000V 400A

        2118908.0.0
        Rated current In (A)
        400
        Rated Voltage Un AC (V)
        1000
        Homologations
        IEC & UL
        Fuses format
        Screw fixing
        Fuses dimension
        80mm
        Number of phase
        1
        Distance (mm)
        80
        Max power dissipation (W)
        34
