Fuse NH00 aR 500V top indicator 125A

    Fuse NH00 aR 500V top indicator 125A

    SIBA
    2000104.125.0
    Product available on request

    Product Request:

    Fuse NH00 aR 500V top indicator 125A

    Fuse NH00 aR 500V top indicator 125A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 3 pcs

    This product has a minimum quantity of 3 and sold by 3

    Download

    Catalog Datasheet
    Class
    aR
    Rated current In (A)
    125
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    500
    Weight (g)
    170
    Format
    NH knife contact
    Dimension
    NH00
    Pre-arcing I2t value (A2s)
    1660
    Total I2t value (A2s)
    12300
    Homologations
    IEC
    Power loss (W)
    25

    Alternatives

    Fuse NH00 aR 690V top indicator 125A
      Available
      Ultrarapid fuses aR - gR

      Fuse NH00 aR 690V top indicator 125A

      SIBA SIBA
      2020920.125.0
      Class
      aR
      Rated current In (A)
      125
      Rated Voltage Un AC (V)
      690
      Rated break.capacity I1 AC (A)
      100000
      Voltage of total I2t test
      690
      Format
      NH knife contact
      Dimension
      NH00
      Pre-arcing I2t value (A2s)
      1200
      Total I2t value (A2s)
      9100
      Homologations
      IEC
      Power loss (W)
      25
