Fuse NH000/NH00C gR 500V top indicator 6A

    Fuse NH000/NH00C gR 500V top indicator 6A

    SIBA
    2000004.6.0
    Product available on request

    Product Request:

    Fuse NH000/NH00C gR 500V top indicator 6A

    Fuse NH000/NH00C gR 500V top indicator 6A

    do not include special characters

    * Required fields



    This product is only sold in boxes of 3 pcs

    This product has a minimum quantity of 3 and sold by 3

    Download

    Catalog Datasheet
    Class
    gR
    Rated current In (A)
    6
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    500
    Weight (g)
    110
    Format
    NH knife contact
    Dimension
    NH00C NH000
    Pre-arcing I2t value (A2s)
    0,72
    Total I2t value (A2s)
    10
    Homologations
    IEC
    Power loss (W)
    2,7

    Accessories

    Fuse holder ceramic NH00 160A 1pole
      Available
      for NH knife fuses

      Fuse holder ceramic NH00 160A 1pole

      2100110.0.0
      Rated current In (A)
      160
      Rated Voltage Un AC (V)
      690
      Homologations
      IEC
      Fuses format
      NH knife contact
      Fuses dimension
      NH00
      Number of phase
      1
      Max power dissipation (W)
      12

      Product available on request

      Fuse base ST NH00 1pole screw fixing
        Available
        for NH knife fuses

        Fuse base ST NH00 1pole screw fixing

        354100.0.0
        Rated current In (A)
        160
        Rated Voltage Un AC (V)
        800
        Fuses format
        NH knife contact
        Fuses dimension
        NH00
        Rated Voltage Un DC (V)
        750
        €7.39
        Fuse holder metal/ceramic NH00 160A 1pole
          Available
          for NH knife fuses

          Fuse holder metal/ceramic NH00 160A 1pole

          2100101.0.0
          Rated current In (A)
          160
          Rated Voltage Un AC (V)
          690
          Homologations
          IEC
          Fuses format
          NH knife contact
          Fuses dimension
          NH00
          Number of phase
          1
          Max power dissipation (W)
          12

          Product available on request

          Fuse base NH00 3P IP20 fix. DINrail/screw - conn. screw
            Available
            for NH knife fuses

            Fuse base NH00 3P IP20 fix. DINrail/screw - conn. screw

            334717.0.0
            Rated current In (A)
            160
            Rated Voltage Un AC (V)
            800
            Format
            NH knife contact
            Dimension
            NH00
            Homologations
            IEC
            Fuses format
            NH knife contact
            Fuses dimension
            NH00
            Rated Voltage Un DC (V)
            750
            Number of phase
            3
            Max power dissipation (W)
            12
            €51.10
            Swich disconn. NH000 3P BS 690V conn. clamp
              Available
              Horizontal switch disconnectors for NH fuses

              Swich disconn. NH000 3P BS 690V conn. clamp

              335005.0.0
              Rated current In (A)
              160
              Rated Voltage Un AC (V)
              690
              Homologations
              IEC
              Fuses format
              NH knife contact
              Fuses dimension
              NH000
              Number of phase
              3
              Max power dissipation (W)
              12
              €94.79
              Swich disconn. NH00 3P BS 690V conn. screw/clamp
                Available
                Horizontal switch disconnectors for NH fuses

                Swich disconn. NH00 3P BS 690V conn. screw/clamp

                335025.0.0
                Rated current In (A)
                160
                Rated Voltage Un AC (V)
                690
                Homologations
                IEC
                Fuses format
                NH knife contact
                Fuses dimension
                NH00
                Number of phase
                3
                Max power dissipation (W)
                12

                Product available on request

                Swich disconn. NH00 3P BS 690V conn. busbar
                  Available
                  Horizontal switch disconnectors for NH fuses

                  Swich disconn. NH00 3P BS 690V conn. busbar

                  335040.0.0
                  Rated current In (A)
                  160
                  Rated Voltage Un AC (V)
                  690
                  Homologations
                  IEC
                  Fuses format
                  NH knife contact
                  Fuses dimension
                  NH00
                  Number of phase
                  3
                  Max power dissipation (W)
                  12

                  Product available on request
