Fuse NH000/NH00C gR 690V top indicator 20A

Manufacturer: SIBA

Reference 2047720.20.0

€26.64

VAT excl.

Product Details

Class: gR
Rated current In (A): 20
Rated Voltage Un AC (V): 690
Rated break.capacity I1 AC (A): 100000
Voltage of total I2t test: 690
Weight (g): 190
Format: NH knife contact
Dimension: NH00C NH000
Pre-arcing I2t value (A2s): 12
Total I2t value (A2s): 91
Homologations: IEC
Power loss (W): 5

Accessories

Available

for NH knife fuses

Fuse holder ceramic NH00 160A 1pole

2100110.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

Product available on request

Available

for NH knife fuses

Fuse base ST NH00 1pole screw fixing

354100.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

800

Fuses format

NH knife contact

Fuses dimension

NH00

Rated Voltage Un DC (V)

750

€7.39

Fuse holder metal/ceramic NH00 160A 3poles + separators

Fuse holder metal/ceramic NH00 160A 3poles + separators 2

Available

for NH knife fuses

Fuse holder metal/ceramic NH00 160A 3poles + separators

2100103.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

Product available on request

Fuse holder metal/ceramic NH00 160A 1pole

Available

for NH knife fuses

Fuse holder metal/ceramic NH00 160A 1pole

2100101.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

Product available on request

Fuse holder polyester ST NH00 3p DIN rail or screw fixing

Available

for NH knife fuses

Fuse holder polyester ST NH00 3p DIN rail or screw fixing

353102.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

€15.82

Fuse holder polyester ST NH00 1P DIN rail or screw fixing

Available

for NH knife fuses

Fuse holder polyester ST NH00 1P DIN rail or screw fixing

352100.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

800

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Rated Voltage Un DC (V)

750

Number of phase

Max power dissipation (W)

€9.92

Available

for NH knife fuses

Grip handle NH00-0-1-2-3 standard

2200102.0.0

Fuses format

NH knife contact

Fuses dimension

NH000 NH00 NH0 NH1 NH2 NH3

€22.66

Grip handle NH00-0-1-2-3 standard with leather cuff

Available

for NH knife fuses

Grip handle NH00-0-1-2-3 standard with leather cuff

2200105.0.0

Rated current In (A)

1000

Fuses format

NH knife contact

Fuses dimension

NH000 NH00 NH0 NH1 NH2 NH3

€121.87

Available

for NH knife fuses

Grip handle NH 000-00-0-1-2-3-4-4a

340001.0.0

Fuses format

NH knife contact

Fuses dimension

NH000 NH00 NH0 NH1 NH2 NH3 NH4 NH4a

€15.55

Fuse base NH00 3P IP20 fix. DINrail/screw - conn. screw

Available

for NH knife fuses

Fuse base NH00 3P IP20 fix. DINrail/screw - conn. screw

334717.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

800

Format

NH knife contact

Dimension

NH00

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Rated Voltage Un DC (V)

750

Number of phase

Max power dissipation (W)

€51.10

Swich disconn. NH000 3P BS 690V conn. clamp

Available

Horizontal switch disconnectors for NH fuses

Swich disconn. NH000 3P BS 690V conn. clamp

335005.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH000

Number of phase

Max power dissipation (W)

€94.79

Swich disconn. NH00 3P BS 690V conn. screw/clamp

Available

Horizontal switch disconnectors for NH fuses

Swich disconn. NH00 3P BS 690V conn. screw/clamp

335025.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

Product available on request

Swich disconn. NH00 3P BS 690V conn. busbar

Available

Horizontal switch disconnectors for NH fuses

Swich disconn. NH00 3P BS 690V conn. busbar

335040.0.0

Rated current In (A)

160

Rated Voltage Un AC (V)

690

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH00

Number of phase

Max power dissipation (W)

Product available on request

Fuse NH000/NH00C gR 690V top indicator 20A
