NR2B - Fuse DIN00 80mm aR 690VAC with ind. lug 400A

    NR2B - Fuse DIN00 80mm aR 690VAC with ind. lug 400A

    FAULTRAP
    152.430.74.0.0
    Product available on request

    Product Request:


    NR2B - Fuse DIN00 80mm aR 690VAC with ind. lug 400A

    NR2B - Fuse DIN00 80mm aR 690VAC with ind. lug 400A

    do not include special characters

    * Required fields



    Download

    Class
    aR
    Rated current In (A)
    400
    Rated Voltage Un AC (V)
    690
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    690
    Format
    Screw fixing
    Dimension
    000-80mm
    Pre-arcing I2t value (A2s)
    33600
    Total I2t value (A2s)
    252000
    Homologations
    IEC & UL
    Power loss (W)
    89
    Time costant L/R (ms)
    2
    Catalog name
    NR2B
