Fuse NH1XL 1500V DC gBat with ind. 200A

Fuse NH1XL 1500V DC gBat with ind. 200A

Manufacturer: SIBA

Reference 2004137.200.0

Product Details

Rated current In (A): 200
Voltage of total I2t test: 85000
Format: NH knife contact
Dimension: NH1XL
Total I2t value (A2s): 14300
Homologations: IEC & UL
Power loss (W): 44
Rated Voltage Un DC (V): 1500
Rated break.capacity I1 DC (A): 100000

Accessories

Fuse holder metal/ceramic NH1XL 1500VAC 1200VDC

Available

for NH knife fuses

Fuse holder metal/ceramic NH1XL 1500VAC 1200VDC

2102801.0.0

Rated current In (A)

200

Rated Voltage Un AC (V)

1500

Homologations

IEC & UL

Fuses format

NH knife contact

Fuses dimension

NH1XL

Rated Voltage Un DC (V)

1000

Number of phase

1

Max power dissipation (W)

32

€87.30

ZMMN - Fuse base NH1XL 1500VDC

Available

for NH knife fuses

ZMMN - Fuse base NH1XL 1500VDC

446.287.28.0.0

Rated current In (A)

250

Rated Voltage Un AC (V)

1500

Homologations

IEC

Fuses format

NH knife contact

Fuses dimension

NH1XL

Rated Voltage Un DC (V)

1500

Number of phase

1

Distance (mm)

232

Max power dissipation (W)

32

€97.91

Grip handle NH1XL NH2XL NH3L

Available

for NH knife fuses

Grip handle NH1XL NH2XL NH3L

340005.0.0

Fuses format

NH knife contact

Product available on request

Fuse base NH1XL 1500VDC 250A

Available

for NH knife fuses

Fuse base NH1XL 1500VDC 250A

358250.0.0

Rated current In (A)

250

Homologations

UL

Fuses format

NH knife contact

Fuses dimension

NH1XL

Rated Voltage Un DC (V)

1500

Number of phase

1

Product available on request

Grip handle NH1XL NH2XL NH3L 1500V distance 120mm -124mm

Grip handle NH1XL NH2XL NH3L 1500V distance 120mm -124mm 2

Available

for NH knife fuses

Grip handle NH1XL NH2XL NH3L 1500V distance 120mm -124mm

2203101.0.0

Rated current In (A)

1000

Rated Voltage Un AC (V)

1600

Fuses format

NH knife contact

Fuses dimension

NH1XL NH3L NH2XL

€183.94

Grip handle NH1XL NH2XL NH3L 1500V with glove 120-124mm

Available

for NH knife fuses

Grip handle NH1XL NH2XL NH3L 1500V with glove 120-124mm

2203102.0.0

Rated current In (A)

1000

Rated Voltage Un AC (V)

1600

Fuses format

NH knife contact

Fuses dimension

NH1XL NH3L NH2XL

Product available on request

Microswitch for fusesNH 000-00-0-1-2-3

Available

for Bolted fuses

Microswitch for fusesNH 000-00-0-1-2-3

357010.0.0

Fuses format

NH knife contact

Fuses dimension

NH000 NH00 NH0 NH1 NH2 NH3

Product available on request
