Fuse SQB3 110mm 900V lateral switch adapter body 82mm 1600A

    Fuse SQB3 110mm 900V lateral switch adapter body 82mm 1600A

    SIBA
    2073552.1600.0
    Product available on request

    Product Request:

    Fuse SQB3 110mm 900V lateral switch adapter body 82mm 1600A

    Fuse SQB3 110mm 900V lateral switch adapter body 82mm 1600A

    do not include special characters

    * Required fields



    Download

    Catalog Datasheet
    Class
    aR
    Rated current In (A)
    1600
    Rated Voltage Un AC (V)
    900
    Rated break.capacity I1 AC (A)
    100000
    Voltage of total I2t test
    1000
    Weight (g)
    1380
    Format
    Screw fixing
    Dimension
    SQB3-110mm
    Pre-arcing I2t value (A2s)
    804000
    Total I2t value (A2s)
    4280000
    Homologations
    IEC
    Power loss (W)
    284

    Accessories

    Fuse holder for SQB fuses size1-2-3 110mm1250A 1400V
      Available
      for Bolted fuses

      Fuse holder for SQB fuses size1-2-3 110mm1250A 1400V

      2132302.0.0
      Rated current In (A)
      1250
      Rated Voltage Un AC (V)
      1400
      Homologations
      IEC & UL
      Fuses format
      Screw fixing
      Fuses dimension
      SQB1 SQB2 SQB3
      Number of phase
      1
      Distance (mm)
      110
      Max power dissipation (W)
      110
      €194.10
