Fuse NH1 gG 500V with striker 50A

    Fuse NH1 gG 500V with striker 50A

    2000913.50.0
    SIBA
    Available
    Class
    gG
    Rated current In (A)
    50
    Rated Voltage Un AC (V)
    500
    Rated break.capacity I1 AC (A)
    120000
    Voltage of total I2t test
    440
    Format
    NH knife contact
    Dimension
    NH1
    Pre-arcing I2t value (A2s)
    5900
    Total I2t value (A2s)
    13600
    Homologations
    IEC
    Power loss (W)
    5,1

    Product available on request


    Catalog
    Datasheet
    Fuse gB NH00 500V 100A

      Fuse gB NH00 500V 100A

      2000103.100.0
      SIBA
      Available
      Class
      gB
      Rated current In (A)
      100
      Rated Voltage Un AC (V)
      500
      Rated break.capacity I1 AC (A)
      120000
      Voltage of total I2t test
      500
      Format
      NH knife contact
      Dimension
      NH00
      Pre-arcing I2t value (A2s)
      3300
      Total I2t value (A2s)
      13000
      Power loss (W)
      10

      Product available on request


      Catalog
      Datasheet
      X800 - Fuse 22x65mm 800VAC gG 20A

        X800 - Fuse 22x65mm 800VAC gG 20A

        349.165.25.0.0
        FAULTRAP
        Available
        Class
        gG
        Rated current In (A)
        20
        Rated Voltage Un AC (V)
        800
        Rated break.capacity I1 AC (A)
        80000
        Voltage of total I2t test
        800
        Format
        Cylindrical
        Dimension
        22x65mm
        Pre-arcing I2t value (A2s)
        650
        Total I2t value (A2s)
        11760
        Homologations
        IEC
        Power loss (W)
        3

        Product available on request


        Catalog
        Datasheet
        Fuse 27x60mm AC 400V 80mm

          Fuse 27x60mm AC 400V 80mm

          5053152.25.0
          SIBA
          Available
          Class
          aSF
          Rated Voltage Un AC (V)
          400
          Rated break.capacity I1 AC (A)
          100000
          Format
          Screw fixing
          Dimension
          27x60mm
          Homologations
          IEC

          Product available on request


          Datasheet
          Fuse 22x58 690VAC gG 12A IEC - 500VAC gR 10A UL

            Fuse 22x58 690VAC gG 12A IEC - 500VAC gR 10A UL

            5006052.12.0
            SIBA
            Available
            Class
            gG
            Rated current In (A)
            12
            Rated Voltage Un AC (V)
            500
            Rated break.capacity I1 AC (A)
            100000
            Voltage of total I2t test
            500
            Format
            Cylindrical
            Dimension
            22x58mm
            Pre-arcing I2t value (A2s)
            60
            Total I2t value (A2s)
            200
            Homologations
            IEC
            Power loss (W)
            1,7

            Product available on request


            Catalog
            Datasheet
            Fuse 800V NH1 gG 200A

              Fuse 800V NH1 gG 200A

              385260.0.0
              DF
              Available
              Class
              gG
              Rated current In (A)
              200
              Rated Voltage Un AC (V)
              800
              Rated break.capacity I1 AC (A)
              80000
              Voltage of total I2t test
              800
              Format
              NH knife contact
              Dimension
              NH1
              Pre-arcing I2t value (A2s)
              108000
              Total I2t value (A2s)
              256350
              Homologations
              IEC
              Power loss (W)
              23,5

              Product available on request


              Catalog
              Datasheet
              Fuse 800V NH1 gG 160A

                Fuse 800V NH1 gG 160A

                385255.0.0
                DF
                Available
                Class
                gG
                Rated current In (A)
                160
                Rated Voltage Un AC (V)
                800
                Rated break.capacity I1 AC (A)
                80000
                Voltage of total I2t test
                800
                Format
                NH knife contact
                Dimension
                NH1
                Pre-arcing I2t value (A2s)
                95300
                Total I2t value (A2s)
                195000
                Homologations
                IEC
                Power loss (W)
                18

                Product available on request


                Catalog
                Datasheet
                Fuse 800V NH1 gG 125A

                  Fuse 800V NH1 gG 125A

                  385250.0.0
                  DF
                  Available
                  Class
                  gG
                  Rated current In (A)
                  125
                  Rated Voltage Un AC (V)
                  800
                  Rated break.capacity I1 AC (A)
                  80000
                  Voltage of total I2t test
                  800
                  Format
                  NH knife contact
                  Dimension
                  NH1
                  Pre-arcing I2t value (A2s)
                  59730
                  Total I2t value (A2s)
                  122215
                  Homologations
                  IEC
                  Power loss (W)
                  14

                  Product available on request


                  Catalog
                  Datasheet
                  Fuse 800V NH1 gG 100A

                    Fuse 800V NH1 gG 100A

                    385245.0.0
                    DF
                    Available
                    Class
                    gG
                    Rated current In (A)
                    100
                    Rated Voltage Un AC (V)
                    800
                    Rated break.capacity I1 AC (A)
                    80000
                    Voltage of total I2t test
                    800
                    Format
                    NH knife contact
                    Dimension
                    NH1
                    Pre-arcing I2t value (A2s)
                    32430
                    Total I2t value (A2s)
                    66355
                    Homologations
                    IEC
                    Power loss (W)
                    12

                    Product available on request


                    Catalog
                    Datasheet
                    Fuse 800V NH1 gG 80A

                      Fuse 800V NH1 gG 80A

                      385240.0.0
                      DF
                      Available
                      Class
                      gG
                      Rated current In (A)
                      80
                      Rated Voltage Un AC (V)
                      800
                      Rated break.capacity I1 AC (A)
                      80000
                      Voltage of total I2t test
                      800
                      Format
                      NH knife contact
                      Dimension
                      NH1
                      Pre-arcing I2t value (A2s)
                      16550
                      Total I2t value (A2s)
                      33855
                      Homologations
                      IEC
                      Power loss (W)
                      10

                      Product available on request


                      Catalog
                      Datasheet
                      Fuse 800V NH1C gG 63A

                        Fuse 800V NH1C gG 63A

                        385235.0.0
                        DF
                        Available
                        Class
                        gG
                        Rated current In (A)
                        63
                        Rated Voltage Un AC (V)
                        800
                        Rated break.capacity I1 AC (A)
                        80000
                        Voltage of total I2t test
                        800
                        Format
                        NH knife contact
                        Dimension
                        NH1
                        Pre-arcing I2t value (A2s)
                        9400
                        Total I2t value (A2s)
                        22670
                        Homologations
                        IEC
                        Power loss (W)
                        6,1

                        Product available on request


                        Catalog
                        Datasheet
                        Fuse 800V NH1C gG 50A

                          Fuse 800V NH1C gG 50A

                          385230.0.0
                          DF
                          Available
                          Class
                          gG
                          Rated current In (A)
                          50
                          Rated Voltage Un AC (V)
                          800
                          Rated break.capacity I1 AC (A)
                          80000
                          Voltage of total I2t test
                          800
                          Format
                          NH knife contact
                          Dimension
                          NH1
                          Pre-arcing I2t value (A2s)
                          4680
                          Total I2t value (A2s)
                          11300
                          Homologations
                          IEC
                          Power loss (W)
                          5,3

                          Product available on request


                          Catalog
                          Datasheet
                          Fuse 800V NH1C gG 40A

                            Fuse 800V NH1C gG 40A

                            385225.0.0
                            DF
                            Available
                            Class
                            gG
                            Rated current In (A)
                            40
                            Rated Voltage Un AC (V)
                            800
                            Rated break.capacity I1 AC (A)
                            80000
                            Voltage of total I2t test
                            800
                            Format
                            NH knife contact
                            Dimension
                            NH1
                            Pre-arcing I2t value (A2s)
                            4600
                            Total I2t value (A2s)
                            11080
                            Homologations
                            IEC
                            Power loss (W)
                            5

                            Product available on request


                            Catalog
                            Datasheet
                            Fuse 800V NH1C gG 35A

                              Fuse 800V NH1C gG 35A

                              385220.0.0
                              DF
                              Available
                              Class
                              gG
                              Rated current In (A)
                              35
                              Rated Voltage Un AC (V)
                              800
                              Rated break.capacity I1 AC (A)
                              80000
                              Voltage of total I2t test
                              800
                              Format
                              NH knife contact
                              Dimension
                              NH1
                              Pre-arcing I2t value (A2s)
                              2780
                              Total I2t value (A2s)
                              6700
                              Homologations
                              IEC
                              Power loss (W)
                              4,8

                              Product available on request


                              Catalog
                              Datasheet
                              Fuse 800V NH1C gG 25A

                                Fuse 800V NH1C gG 25A

                                385210.0.0
                                DF
                                Available
                                Class
                                gG
                                Rated current In (A)
                                25
                                Rated Voltage Un AC (V)
                                800
                                Rated break.capacity I1 AC (A)
                                80000
                                Voltage of total I2t test
                                800
                                Format
                                NH knife contact
                                Dimension
                                NH1
                                Pre-arcing I2t value (A2s)
                                1150
                                Total I2t value (A2s)
                                2770
                                Homologations
                                IEC
                                Power loss (W)
                                4,1

                                Product available on request


                                Catalog
                                Datasheet
                                Fuse NH2 gG 500V top indicator 425A

                                  Fuse NH2 gG 500V top indicator 425A

                                  381385.0.0
                                  DF
                                  Available
                                  Class
                                  gG
                                  Rated current In (A)
                                  425
                                  Rated Voltage Un AC (V)
                                  500
                                  Rated break.capacity I1 AC (A)
                                  120000
                                  Voltage of total I2t test
                                  500
                                  Format
                                  NH knife contact
                                  Dimension
                                  NH2
                                  Pre-arcing I2t value (A2s)
                                  589800
                                  Total I2t value (A2s)
                                  1851960
                                  Power loss (W)
                                  35,2

                                  Product available on request


                                  Catalog
                                  Fuse NH3 800V gG 315A

                                    Fuse NH3 800V gG 315A

                                    3803315.0.0
                                    NIKDIM
                                    Available
                                    Class
                                    gG
                                    Rated current In (A)
                                    315
                                    Rated Voltage Un AC (V)
                                    800
                                    Rated break.capacity I1 AC (A)
                                    50000
                                    Format
                                    NH knife contact
                                    Dimension
                                    NH3
                                    Homologations
                                    IEC
                                    Power loss (W)
                                    32,7

                                    Product available on request


                                    Catalog
                                    Datasheet
                                    Fuse NH3 800V gG 400A

                                      Fuse NH3 800V gG 400A

                                      3803400.0.0
                                      NIKDIM
                                      Available
                                      Class
                                      gG
                                      Rated current In (A)
                                      400
                                      Rated Voltage Un AC (V)
                                      800
                                      Rated break.capacity I1 AC (A)
                                      50000
                                      Format
                                      NH knife contact
                                      Dimension
                                      NH3
                                      Homologations
                                      IEC
                                      Power loss (W)
                                      38,5

                                      Product available on request


                                      Catalog
                                      Datasheet
                                      Fuse NH3 800V gG 250A

                                        Fuse NH3 800V gG 250A

                                        3803250.0.0
                                        NIKDIM
                                        Available
                                        Class
                                        gG
                                        Rated current In (A)
                                        250
                                        Rated Voltage Un AC (V)
                                        800
                                        Rated break.capacity I1 AC (A)
                                        50000
                                        Format
                                        NH knife contact
                                        Dimension
                                        NH3
                                        Homologations
                                        IEC
                                        Power loss (W)
                                        22,9

                                        Product available on request


                                        Catalog
                                        Datasheet
                                        Fuse NH3 800V gG 200A

                                          Fuse NH3 800V gG 200A

                                          3803200.0.0
                                          NIKDIM
                                          Available
                                          Class
                                          gG
                                          Rated current In (A)
                                          200
                                          Rated Voltage Un AC (V)
                                          800
                                          Rated break.capacity I1 AC (A)
                                          50000
                                          Format
                                          NH knife contact
                                          Dimension
                                          NH3
                                          Homologations
                                          IEC
                                          Power loss (W)
                                          22,3

                                          Product available on request


                                          Catalog
                                          Datasheet
                                          Fuse NH2 800V gG 400A

                                            Fuse NH2 800V gG 400A

                                            3802400.0.0
                                            NIKDIM
                                            Available
                                            Class
                                            gG
                                            Rated current In (A)
                                            400
                                            Rated Voltage Un AC (V)
                                            800
                                            Rated break.capacity I1 AC (A)
                                            50000
                                            Format
                                            NH knife contact
                                            Dimension
                                            NH2
                                            Homologations
                                            IEC
                                            Power loss (W)
                                            38,5

                                            Product available on request


                                            Datasheet

                                            Filter by

                                            Manufacturer
                                            more... less
                                            Class
                                            more... less
                                            Rated Voltage Un AC (V)
                                            32 1140
                                            Rated Voltage Un DC (V)
                                            400 1000
                                            Rated current In (A)
                                            0.16 1600
                                            Format
                                            more... less
                                            Dimension
                                            Homologations
                                            more... less
                                            Pre-arcing I2t value (A2s)
                                            0.08 14000000
                                            Total I2t value (A2s)
                                            0.35 35000000
