Fuse 14x51 gR 690V (IEC)/700V (UL) 50A

    Fuse 14x51 gR 690V (IEC)/700V (UL) 50A

    492024.0.0
    DF
    Available
    Class
    gR
    Rated current In (A)
    50
    Rated Voltage Un AC (V)
    690
    Rated break.capacity I1 AC (A)
    200000
    Voltage of total I2t test
    690
    Format
    Cylindrical
    Dimension
    14x51mm
    Pre-arcing I2t value (A2s)
    350
    Total I2t value (A2s)
    2200
    Homologations
    IEC & UL
    €18.02

    Fuse 22x58 gR 690V UL 20A

      Fuse 22x58 gR 690V UL 20A

      492033.0.0
      DF
      Available
      Class
      gR
      Rated current In (A)
      20
      Rated Voltage Un AC (V)
      690
      Rated break.capacity I1 AC (A)
      200000
      Voltage of total I2t test
      690
      Format
      Cylindrical
      Dimension
      22x58mm
      Pre-arcing I2t value (A2s)
      24
      Total I2t value (A2s)
      154
      Homologations
      IEC & UL
      Power loss (W)
      6
      €18.45

      Fuse NH00 gG 500V top indicator 125A

        Fuse NH00 gG 500V top indicator 125A

        381070.0.0
        DF
        Available
        Class
        gG
        Rated current In (A)
        125
        Rated Voltage Un AC (V)
        500
        Rated break.capacity I1 AC (A)
        120000
        Voltage of total I2t test
        500
        Format
        NH knife contact
        Dimension
        NH00
        Pre-arcing I2t value (A2s)
        40500
        Total I2t value (A2s)
        136865
        Homologations
        IEC
        Power loss (W)
        9
        €6.15

        Catalog
        Fuse NH3C gG 500V with top indicator 400A

          Fuse NH3C gG 500V with top indicator 400A

          381455.0.0
          DF
          Available
          Class
          gG
          Rated current In (A)
          400
          Rated Voltage Un AC (V)
          500
          Rated break.capacity I1 AC (A)
          120000
          Voltage of total I2t test
          500
          Format
          NH knife contact
          Dimension
          NH3C
          Pre-arcing I2t value (A2s)
          444000
          Total I2t value (A2s)
          1670000
          Homologations
          IEC
          Power loss (W)
          32,6
          €31.96

          Catalog
          Fuse NH0 gG 690V double indicator 6A

            Fuse NH0 gG 690V double indicator 6A

            382110.0.0
            DF
            Available
            Class
            gG
            Rated current In (A)
            6
            Rated Voltage Un AC (V)
            690
            Rated break.capacity I1 AC (A)
            80000
            Voltage of total I2t test
            690
            Format
            NH knife contact
            Dimension
            NH0
            Pre-arcing I2t value (A2s)
            103
            Total I2t value (A2s)
            300
            Homologations
            IEC
            Power loss (W)
            1,3
            €10.50

            Catalog
            Fuse NH3 gG 690V double indicator 315A

              Fuse NH3 gG 690V double indicator 315A

              382445.0.0
              DF
              Available
              Class
              gG
              Rated current In (A)
              315
              Rated Voltage Un AC (V)
              690
              Rated break.capacity I1 AC (A)
              80000
              Voltage of total I2t test
              690
              Format
              NH knife contact
              Dimension
              NH3
              Pre-arcing I2t value (A2s)
              264000
              Total I2t value (A2s)
              850000
              Homologations
              IEC
              Power loss (W)
              30
              €37.41

              Catalog
              Fuse NH2 gG 500V with striker 200A

                Fuse NH2 gG 500V with striker 200A

                395350.0.0
                DF
                Available
                Class
                gG
                Rated current In (A)
                200
                Rated Voltage Un AC (V)
                500
                Rated break.capacity I1 AC (A)
                120000
                Voltage of total I2t test
                500
                Format
                NH knife contact
                Dimension
                NH2
                Pre-arcing I2t value (A2s)
                98100
                Total I2t value (A2s)
                282540
                Homologations
                IEC
                Power loss (W)
                16,6
                €79.26

                Catalog
                Datasheet
                Fuse 22x58 400V aM 125A

                  Fuse 22x58 400V aM 125A

                  442015.0.0
                  DF
                  Available
                  Class
                  aM
                  Rated current In (A)
                  125
                  Rated Voltage Un AC (V)
                  400
                  Rated break.capacity I1 AC (A)
                  120000
                  Voltage of total I2t test
                  400
                  Format
                  Cylindrical
                  Dimension
                  22x58mm
                  Homologations
                  IEC
                  Power loss (W)
                  8,42
                  €3.38

                  Datasheet
                  Datasheet
                  Fuse 14x51 gR 690V (IEC)/700V (UL) 12A

                    Fuse 14x51 gR 690V (IEC)/700V (UL) 12A

                    492018.0.0
                    DF
                    Available
                    Class
                    gR
                    Rated current In (A)
                    12
                    Rated Voltage Un AC (V)
                    690
                    Rated break.capacity I1 AC (A)
                    200000
                    Voltage of total I2t test
                    690
                    Format
                    Cylindrical
                    Dimension
                    14x51mm
                    Pre-arcing I2t value (A2s)
                    8,4
                    Total I2t value (A2s)
                    68
                    Homologations
                    IEC & UL
                    Power loss (W)
                    3,54
                    €15.02

                    Fuse NH3 1000VDC gPV 400A

                      Fuse NH3 1000VDC gPV 400A

                      373455.0.0
                      DF
                      Available
                      Class
                      gPV
                      Rated current In (A)
                      400
                      Voltage of total I2t test
                      1000
                      Format
                      NH knife contact
                      Dimension
                      NH3
                      Pre-arcing I2t value (A2s)
                      104400
                      Total I2t value (A2s)
                      182600
                      Homologations
                      IEC
                      Power loss (W)
                      51
                      Rated Voltage Un DC (V)
                      1000
                      Rated break.capacity I1 DC (A)
                      30000

                      Product available on request


                      Catalog
                      Fuse 10x38 1000VDC gPV 8A

                        Fuse 10x38 1000VDC gPV 8A

                        491615.0.0
                        DF
                        Available
                        Class
                        gPV
                        Rated current In (A)
                        8
                        Voltage of total I2t test
                        1000
                        Format
                        Cylindrical
                        Dimension
                        10x38mm
                        Pre-arcing I2t value (A2s)
                        7
                        Total I2t value (A2s)
                        17
                        Homologations
                        IEC
                        Power loss (W)
                        2
                        Rated Voltage Un DC (V)
                        1000
                        Rated break.capacity I1 DC (A)
                        30000
                        €20.02

                        Catalog
                        Fuse 10x38 1000VDC gPV 12A

                          Fuse 10x38 1000VDC gPV 12A

                          491625.0.0
                          DF
                          Available
                          Class
                          gPV
                          Rated current In (A)
                          12
                          Voltage of total I2t test
                          1000
                          Format
                          Cylindrical
                          Dimension
                          10x38mm
                          Pre-arcing I2t value (A2s)
                          27
                          Total I2t value (A2s)
                          68
                          Homologations
                          IEC
                          Power loss (W)
                          2,4
                          Rated Voltage Un DC (V)
                          1000
                          Rated break.capacity I1 DC (A)
                          30000
                          €20.02

                          Catalog
                          Fuse 10x38 600VDC gPV 8A

                            Fuse 10x38 600VDC gPV 8A

                            491915.0.0
                            DF
                            Available
                            Class
                            gPV
                            Rated current In (A)
                            8
                            Voltage of total I2t test
                            600
                            Format
                            Cylindrical
                            Dimension
                            10x38mm
                            Pre-arcing I2t value (A2s)
                            25
                            Total I2t value (A2s)
                            55
                            Homologations
                            IEC
                            Power loss (W)
                            2,55
                            Rated Voltage Un DC (V)
                            600
                            Rated break.capacity I1 DC (A)
                            30000

                            Product available on request


                            Catalog
                            Datasheet
                            Fuse 10x38 600VDC gPV 10A

                              Fuse 10x38 600VDC gPV 10A

                              491920.0.0
                              DF
                              Available
                              Class
                              gPV
                              Rated current In (A)
                              10
                              Voltage of total I2t test
                              600
                              Format
                              Cylindrical
                              Dimension
                              10x38mm
                              Pre-arcing I2t value (A2s)
                              11
                              Total I2t value (A2s)
                              27,9
                              Homologations
                              IEC
                              Power loss (W)
                              2,58
                              Rated Voltage Un DC (V)
                              600
                              Rated break.capacity I1 DC (A)
                              30000

                              Product available on request


                              Catalog
                              Datasheet
                              Fuse NH3 1000VDC gPV 355A

                                Fuse NH3 1000VDC gPV 355A

                                373450.0.0
                                DF
                                Available
                                Class
                                gPV
                                Rated current In (A)
                                355
                                Voltage of total I2t test
                                1000
                                Format
                                NH knife contact
                                Dimension
                                NH3
                                Pre-arcing I2t value (A2s)
                                74700
                                Total I2t value (A2s)
                                130700
                                Homologations
                                IEC
                                Power loss (W)
                                46,5
                                Rated Voltage Un DC (V)
                                1000
                                Rated break.capacity I1 DC (A)
                                30000

                                Product available on request


                                Catalog
                                Fuse 10x38 600VDC gPV 3A

                                  Fuse 10x38 600VDC gPV 3A

                                  491904.0.0
                                  DF
                                  Available
                                  Class
                                  gPV
                                  Rated current In (A)
                                  3
                                  Voltage of total I2t test
                                  600
                                  Format
                                  Cylindrical
                                  Dimension
                                  10x38mm
                                  Pre-arcing I2t value (A2s)
                                  9
                                  Total I2t value (A2s)
                                  19,6
                                  Homologations
                                  IEC
                                  Power loss (W)
                                  1,35
                                  Rated Voltage Un DC (V)
                                  600
                                  Rated break.capacity I1 DC (A)
                                  30000

                                  Product available on request


                                  Catalog
                                  Datasheet
                                  Fuse 10x38 600VDC gPV 4A

                                    Fuse 10x38 600VDC gPV 4A

                                    491905.0.0
                                    DF
                                    Available
                                    Class
                                    gPV
                                    Rated current In (A)
                                    4
                                    Voltage of total I2t test
                                    600
                                    Format
                                    Cylindrical
                                    Dimension
                                    10x38mm
                                    Pre-arcing I2t value (A2s)
                                    3
                                    Total I2t value (A2s)
                                    6,6
                                    Homologations
                                    IEC
                                    Power loss (W)
                                    1,84
                                    Rated Voltage Un DC (V)
                                    600
                                    Rated break.capacity I1 DC (A)
                                    30000

                                    Product available on request


                                    Catalog
                                    Datasheet
                                    Fuse 10x38 1000VDC gPV 20A

                                      Fuse 10x38 1000VDC gPV 20A

                                      491635.0.0
                                      DF
                                      Available
                                      Class
                                      gPV
                                      Rated current In (A)
                                      20
                                      Voltage of total I2t test
                                      1000
                                      Format
                                      Cylindrical
                                      Dimension
                                      10x38mm
                                      Pre-arcing I2t value (A2s)
                                      158
                                      Total I2t value (A2s)
                                      294
                                      Homologations
                                      IEC
                                      Power loss (W)
                                      3,2
                                      Rated Voltage Un DC (V)
                                      1000
                                      Rated break.capacity I1 DC (A)
                                      30000
                                      €20.02

                                      Catalog
                                      Fuse 10x38 600VDC gPV 20A

                                        Fuse 10x38 600VDC gPV 20A

                                        491935.0.0
                                        DF
                                        Available
                                        Class
                                        gPV
                                        Rated current In (A)
                                        20
                                        Voltage of total I2t test
                                        600
                                        Format
                                        Cylindrical
                                        Dimension
                                        10x38mm
                                        Pre-arcing I2t value (A2s)
                                        85
                                        Total I2t value (A2s)
                                        212
                                        Homologations
                                        IEC
                                        Power loss (W)
                                        2,9
                                        Rated Voltage Un DC (V)
                                        600
                                        Rated break.capacity I1 DC (A)
                                        30000

                                        Product available on request


                                        Catalog
                                        Datasheet
                                        Fuse 14x51 gPV 1000VDC 25A

                                          Fuse 14x51 gPV 1000VDC 25A

                                          491650.0.0
                                          DF
                                          Available
                                          Class
                                          gPV
                                          Rated current In (A)
                                          25
                                          Voltage of total I2t test
                                          1000
                                          Format
                                          Cylindrical
                                          Dimension
                                          14x51mm
                                          Pre-arcing I2t value (A2s)
                                          275
                                          Rated Voltage Un DC (V)
                                          1000
                                          Rated break.capacity I1 DC (A)
                                          30000

                                          Product available on request


                                          Catalog
                                          Fuse 10x38 600VDC gPV 12A

                                            Fuse 10x38 600VDC gPV 12A

                                            491925.0.0
                                            DF
                                            Available
                                            Class
                                            gPV
                                            Rated current In (A)
                                            12
                                            Voltage of total I2t test
                                            600
                                            Format
                                            Cylindrical
                                            Dimension
                                            10x38mm
                                            Pre-arcing I2t value (A2s)
                                            25
                                            Total I2t value (A2s)
                                            62,8
                                            Homologations
                                            IEC
                                            Power loss (W)
                                            2,6
                                            Rated Voltage Un DC (V)
                                            600
                                            Rated break.capacity I1 DC (A)
                                            30000

                                            Product available on request


                                            Catalog
                                            Datasheet
                                            Fuse 10x38 600VDC gPV 5A

                                              Fuse 10x38 600VDC gPV 5A

                                              491906.0.0
                                              DF
                                              Available
                                              Class
                                              gPV
                                              Rated current In (A)
                                              5
                                              Voltage of total I2t test
                                              600
                                              Format
                                              Cylindrical
                                              Dimension
                                              10x38mm
                                              Pre-arcing I2t value (A2s)
                                              4,4
                                              Total I2t value (A2s)
                                              9,6
                                              Homologations
                                              IEC
                                              Power loss (W)
                                              2,2
                                              Rated Voltage Un DC (V)
                                              600
                                              Rated break.capacity I1 DC (A)
                                              30000

                                              Product available on request


                                              Catalog
                                              Datasheet
                                              Fuse 10x38 600VDC gPV 6A

                                                Fuse 10x38 600VDC gPV 6A

                                                491910.0.0
                                                DF
                                                Available
                                                Class
                                                gPV
                                                Rated current In (A)
                                                6
                                                Voltage of total I2t test
                                                600
                                                Format
                                                Cylindrical
                                                Dimension
                                                10x38mm
                                                Pre-arcing I2t value (A2s)
                                                8,5
                                                Total I2t value (A2s)
                                                18,8
                                                Homologations
                                                IEC
                                                Power loss (W)
                                                2,4
                                                Rated Voltage Un DC (V)
                                                600
                                                Rated break.capacity I1 DC (A)
                                                30000

                                                Product available on request


                                                Catalog
                                                Datasheet
